General
Device Type
Security appliance
Processor / Memory / Storage
Networking
Form Factor
Rack-mountable
Connectivity Technology
Wired
Performance
Firewall throughput: 6 Gbps
Maximum throughput FW + AVC: 3 Gbps
Maximum throughput FW + AVC + NGIPS: 3 Gbps
IPSec VPN throughput (1024B TCP w/Fastpath): 1 Gbps
Multiprotocol firewall throughput: 3 Gbps
IPsec VPN throughput (450B UDP L2L test): 700 Mbps
Capacity
New connections per second with AVC: 16000
Concurrent sessions with AVC: 1200000
Virtual interfaces (VLANs): 600
Concurrent firewall connections: 1500000
VPN peers: 3500
Security contexts: 2 (maximum 25)
New connections per second: 28000
Status Indicators
Power, system, fan, Internet, SSD activity
Features
VLAN support, auto-uplink (auto MDI/MDI-X), URL filtering, DDos attack prevention, clustering technology, 4 fans, Application Visibility and Control (AVC), auto duplex mode
Expansion / Connectivity
Expansion Slots
1 (total) / 1 (free) x expansion slot
Interfaces
12 x 1000Base-T - RJ-45
4 x 1000Base-X
1 x 1000Base-T (management) - RJ-45
1 x serial - RJ-45
1 x USB 2.0 - Type A
Miscellaneous
Included Accessories
Grounding kit, mounting screws, 2 rack mount brackets, console cable PC terminal adapter, 2 x cable management brackets
Power
Power Device
Internal power supply
Voltage Required
AC 100 - 240 V (50 - 60 Hz)
Software / System Requirements
Software Included
Cisco ASA 9.8
Manufacturer Warranty
Service & Support
Limited warranty - advance hardware replacement - 90 days - response time: 10 days
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 85% (non-condensing)
