General
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol
NTP, PPPoE, PPPoA, IPoE, FTP, DHCP, HTTP, IPv6
Remote Management Protocol
Telnet, HTTP, TFTP, SSH, CLI, TR-069, TR-098, TR-111, NTP, DHCP, IPv6, TR-181
Authentication Method
Secure Shell (SSH)
Features
MAC encapsulation routing, Syslog support, Stateful Packet Inspection (SPI), DoS attack prevention, packet filtering, firmware upgradable, Quality of Service (QoS), DHCP server, reset button, DHCP relay, DHCP client, Rom-D support, VLAN group, G.INP, G.Vector
Compliant Standards
IEEE 802.1Q
Status Indicators
Power, LAN, VDSL
Line Properties
Framing Format
ANSI T1.413
Communications
Digital Signaling Protocol
ADSL, VDSL, ADSL2, ADSL2+, VDSL2
Protocols & Specifications
ITU G.992.1 (G.DMT), ITU G.992.5, ITU G.993.1, ITU G.993.2, ITU G.992.3
Expansion / Connectivity
Interfaces
WAN: 1 x VDSL2 / ADSL2+ - RJ-11 ¦ LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Power
Power Device
External power adapter
Dimensions & Weight
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
