General
Device Type
Network management device
Built-in Devices
1.3" touch screen display, NVR
Processor / Memory / Storage
Processors Installed
1 x 1.7 GHz
Networking
Form Factor
Rack-mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet, 2.5 Gigabit Ethernet
Switching Protocol
Ethernet
Performance
IPS throughput: 3.5 Gbps ¦ Intrusion detection throughput: 3.5 Gbps
Status Indicators
HDD activity, RPS (Redundant Power Supply), link/activity, HDD fault
Features
Routing, Intrusion Detection System (IDS), Intrusion Prevention System (IPS), firmware upgradable, reset button, 8KV ESD Protector (contact discharge), 15KV ESD Protector (air-gap discharge), Bluetooth management
Compliant Standards
IEEE 802.3af, IEEE 802.3at
Expansion / Connectivity
Expansion Bays
1 (total) / 1 (free) x internal - 2.5" / 3.5"
Interfaces
6 x 1000Base-T (PoE) - RJ-45 - 15.4 W ¦ 2 x 1000Base-T (PoE+) - RJ-45 - 30 W ¦ 1 x 10Gb Ethernet - SFP+ ¦ 1 x 2.5 GBase-T - RJ-45 (WAN) ¦ 1 x 10Gb Ethernet - SFP+ (WAN)
Miscellaneous
Compliant Standards
IC, FCC
Power
Power Over Ethernet (PoE) Supported
PoE+
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Software / System Requirements
Environmental Parameters
Min Operating Temperature
-10 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
