ZyXEL SFP10G-SR - SFP+ transceiver module

Productcode: SFP10G-SR-ZZ0101F | EAN/UPC: 0760559120719

€ 163,82 excl.btw

Zyxel SFP10G-SR - SFP+ transceiver module - 10GbE - 10GBase-SR - LC multi-mode - up to 300 m - 850 nm - for Zyxel XGS1910-24, XGS1910-48

Standard-based design assures compatibility
Hot-swappable design facilitates network maintenance
Bi-directional transceivers maximizes usage of existing fiber plant
Supporting Digital Diagnostics Monitoring Interface (DDMI) SFP enhances management capability

Op voorraad: 22 stuk(s)

Levertijd:

Product:
ZyXEL SFP10G-SR - SFP+ transceiver module

€ 198,22 incl. 21% btw € 163,82excl. 21% btw

Winkelwagen Offerte

Omschrijving

Zyxel SFP10G-SR - SFP+ transceiver module - 10GbE - 10GBase-SR - LC multi-mode - up to 300 m - 850 nm - for Zyxel XGS1910-24, XGS1910-48

Product features

Standard-based design assures compatibility
The ZyXEL transceiver family follows industry standards to assure compatibility with switches from other manufacturers without barrier set by proprietary technologies.
Hot-swappable design facilitates network maintenance
Independent transceiver design provides the highest network maintenance flexibility. Transceivers can be freely added when required, and infrastructure upgrades or transceiver repairs can be done easily by just replacing the transceiver instead of the whole device.
Bi-directional transceivers maximizes usage of existing fiber plant
Traditional fiber optic networking requires two strands of fiber to accomplish communications, in which one strand is reserved for sending signals, while the other is for receiving. On the other hand, bi-directional, dual-wavelength transceivers can establish communications over just one strand of fiber by using two separate optical wavelengths: one receives and the other transmits signals. Transmission capacity can be expanded immediately without additional cost laying fiber.
Supporting Digital Diagnostics Monitoring Interface (DDMI) SFP enhances management capability
The enhanced digital interface enables a real time link to be established between the switch and the SFP transceiver. This enables the switch to access operating parameters within the fiber link. This includes digital features such as soft control and monitoring of SFP I/O signals.

Specificaties

General

Device Type

SFP+ transceiver module

Form Factor

Plug-in module

Networking

Connectivity Technology

Wired

Cabling Type

10GBase-SR

Data Link Protocol

10GbE

Data Transfer Rate

10 Gbps

Optical Wave Length

850 nm

Max Transfer Distance

300 m

Features

Hot swap module replacement, Digital Diagnostics Monitoring Interface (DDMI)

Expansion / Connectivity

Interfaces

1 x Ethernet 10GBase-SR - LC multi-mode x 2

Compatible Slots

1 x SFP+

Miscellaneous

Compliant Standards

TUV, Laser Class 1, FCC CFR21 Part 1040, FDA, MSA

Dimensions & Weight

Width

1.48 cm

Depth

5.65 cm

Height

1.185 cm

Weight

20 g

Manufacturer Warranty

Service & Support

Limited warranty - 5 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

70 °C

Compatibility Information

Designed For

Zyxel XGS1910-24, XGS1910-48

This data is supplied by 1WorldSync and matched through an automated process. Truedata is not responsible for errors in this data.

Productvideo

Heb je zelf een goede video voor dit product? Youtube video indienen

Beschikbare brochures

Manufacturer's data sheet
