General
Device Type
Radio access point
Networking
Form Factor
Wall / ceiling mountable
Connectivity Technology
Wireless
Line Coding Format
1024 QAM
Data Link Protocol
Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
Spread Spectrum Method
OFDMA
Network / Transport Protocol
PPPoE
Frequency Band
2.4 GHz, 5 GHz
Performance
Maximum data rate (5 GHz): 1.2 Gbps
Maximum data rate (2.4 GHz): 574 Mbps
Features
Firewall protection, manageable, static IP mode, Trusted Platform Module (TPM), reset button, Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, security lock slot (cable lock sold separately), Advanced Cellular Coexistence (ACC), MU-MIMO technology, 2x2 MIMO technology, Bluetooth (BLE) clients support, Target Wait Time (TWT), Smart Mesh technology, BSS Coloring
Encryption Algorithm
WPA2, WPA3
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Aerial
Directivity
Omni-directional
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Communications Technology
Bluetooth Low Energy (LE)
Expansion / Connectivity
Interfaces
1 x Ethernet 1000 (uplink)
Miscellaneous
Included Accessories
Wall/ceiling rail mounting clip
Cables Included
1 x network cable
1 x power adapter
1 x power cable (EU)
Compliant Standards
UL 2043, EN 60601-1-2, EN 60601-1-1
Power
Power Over Ethernet (PoE) Supported
PoE
Power Device
External power adapter
Software / System Requirements
Software Included
InstantOn
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Technical support - phone consulting - 90 days
Product info support - web support - 1 year
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
