General
Device Type
Switch - 8 ports - Managed
Enclosure Type
Rack-mountable 1U
Ports
8 x 32Gb Fibre Channel QSFP
Performance
Aggregate bandwidth: 2 Tbps
Port-to-port latency: 700 ns
Capacity
Maximum frame size: 2112
Remote Management Protocol
SNMP 1, SNMP 3, HTTP, HTTPS, SMI-S, SSH, SSH-2, CLI
Authentication Method
RADIUS, TACACS+, LDAP, DH-CHAP, FCAP
Features
ISL support, Syslog support, manageable, QoS, RSCN support, SFTP client, SFTP server, ISL Trunking, FSPF, FDMI, SCP, RBAC, DPS, RCS, SNS, FPI monitoring, SDDQ, DFP, Enhanced BB Credit Recovery
Expansion / Connectivity
Interfaces
8 x 32Gb Fibre Channel QSFP
1 x 100Base-TX RJ-45 management
1 x console RJ-45 management
1 x USB Type A
Power
Power Device
Internal power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 120/230 V (50/60 Hz)
Miscellaneous
Cables Included
1 x serial cable
Rack Mounting Kit
Included
Software / System Requirements
Software Included
Advanced Fabric OS, Advanced Web Tools, Advanced Zoning, Power Pack+, ISL Trunking, Extended Fabric
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 1 year - on-site
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 85% (non-condensing)
Min Storage Temperature
-25 °C
Max Storage Temperature
70 °C
