General
Device Type
Host bus adapter
Interface (Bus) Type
PCI Express 3.0 x8
Networking
Ports
32Gb Fibre Channel x 1
Connectivity Technology
Wired
Data Link Protocol
32Gb Fibre Channel
Features
Auto-negotiation, firmware upgradable, Quality of Service (QoS), Forward Error Correction (FEC), Fabric-Device Management Interface (FDMI), Fabric-Assigned port WorldWide Name (FA-WWN), Link cable beacon (LCB), Class-specific Control (CS_CTL), D-Port Diagnostics, FC Ping, FC Trace, Read Diagnostic Parameters (RDP)
Expansion / Connectivity
Interfaces
1 x 32Gb Fibre Channel - SFP+
Miscellaneous
Included Accessories
Low-profile bracket, 32Gb SFP+
Software / System Requirements
OS Required
Red Hat Enterprise Linux 7.2, Microsoft Windows Server 2012 R2 with Hyper-V (64-bit), Microsoft Windows Server 2012 with Hyper-V (64-bit)
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - parts - 3 years ¦ Technical support - phone consulting - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
15 - 80% (non-condensing)
Compatibility Information
Designed For
HPE Apollo 4200 Gen10, 4200 Gen10 336TB Archive Node with 25Gb NIC for Qumulo, 4510 Gen10 ¦ HPE Nimble Storage dHCI Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 ¦ HPE ProLiant DL360 Gen10, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Base, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL385 Gen10 Plus, DL385 Gen10 Plus Entry, XL190r Gen10, XL190r Gen10 for HPE Ezmeral Container Platform, XL270d Gen10, XL270d Gen10 for HPE Ezmeral Container Platform, XL645d Gen10 Plus
