General
Device Type
Switch - 48 ports - L3 - Managed
Enclosure Type
Desktop, rack-mountable 1U
Subtype
40 Gigabit Ethernet
Ports
48 x 10GBase-T + 6 x 40 Gigabit QSFP+
Performance
Bandwidth: 1.44 Tbps
Capacity
Longest prefix match (LPM) entries (IPv4): 16000
Host table entries (IPv4): 88000
MAC addresses: 160000
IPv4 routes (Multicast): 32000
Virtual interfaces (VLANs): 4096
Remote Management Protocol
SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2
Authentication Method
RADIUS, TACACS+
Features
Flow control, modular design, load balancing, VLAN support, WRR queuing, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, WRED, STP support, RSTP support, MSTP support, ACL support, QoS, RADIUS support, RDMA support, LLDP support, LACP, DSCP support
Compliant Standards
IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 801.1p, IEEE 802.3ba
Expansion / Connectivity
Interfaces
48 x 10GBase-T RJ-45
6 x 40Gbit LAN QSFP+ uplink
Expansion Slots
1 (total) / 0 (free) x Expansion Slot
Installed Modules Qty (Max)
1 (installed) / 1 (max)
Power
Power Device
Internal power supply (not installed) - hot-plug
Miscellaneous
Compliant Standards
CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1 Second Edition, GB 4943, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, EN 61000-3-1, VCCI Class A, KN22 Class A, AS/NZS CISPR 22, EN 300386
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - advance parts replacement - 1 year - response time: 10 days
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
