General
Device Type
Switch - 8 ports - L3 Lite - smart
Enclosure Type
Desktop, rack-mountable
Ports
4 x 100/1000/2.5G + 4 x 1/2.5/5/10GBase-T + 2 x 10 Gigabit SFP+ (uplink)
Performance
Fabric throughput: 140 Gbps ¦ Forwarding rate (64-byte packets): 14.8 Mpps ¦ 2.5 Gbps copper latency (64-byte packets): 5.903 µs ¦ 2.5 Gbps copper latency (1518-byte packets): 6.040 µs ¦ 2.5 Gbps copper latency (9216-byte packets): 6.079 µs ¦ 10 Gbps copper latency (64-byte packets): 2.420 µs ¦ 10 Gbps copper latency (1518-byte packets): 2.501 µs ¦ 10 Gbps copper latency (9216-byte packets): 2.499 µs ¦ 10 Gbps fibre latency (64-byte packets): 1.257 µs ¦ 10 Gbps fibre latency (1518-byte packets): 1.337 µs ¦ 10 Gbps fibre latency (9216-byte packets): 1.348 µs
Capacity
Packet buffer size: 2 MB ¦ ACL entries (ingress): 100 ¦ VLANs supported: 256 ¦ IGMP groups: 256 ¦ Priority queues: 8 ¦ DHCP snooping entries: 256
MAC Address Table Size
32000 entries
Routing Protocol
IGMPv2, IGMP, IGMPv3, MLDv2, MLD, MSTP, RSTP, STP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS, IPv6, RSTP, TACACS+, RADIUS
Encryption Algorithm
TLS 1.2
Authentication Method
RADIUS, TACACS+, Extensible Authentication Protocol (EAP)
Features
Flow control, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, store and forward, Broadcast Storm Control, full duplex mode, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, DHCP snooping, Access Control List (ACL) support, LLDP support, Link Aggregation Control Protocol (LACP), DHCP client, Dynamic VLAN Support (GVRP), dual firmware images, loop prevention, Strict Priority (SP), 802.1x authentication, cloud managed, VoIP support, DiffServ Code Point (DSCP) support, 2 fans, cable test, Bridge protocol data unit (BPDU), IGMP querier, DNS client, Voice VLAN, LLDP-MED, Guest VLAN, User Datagram Protocol (UDP), protected ports, Zero-touch provisioning (ZTP), Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), loopback detection, egress rate limiting, block unknown multicast, Advanced QoS, Unknown Storm Control, Extensible Authentication Protocol over LAN (EAPOL)
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az, UPnP
Status Indicators
Power, fan, link/activity/speed
Expansion / Connectivity
Interfaces
4 x 100/1000/2.5G RJ-45 ¦ 4 x 1/2.5/5/10GBase-T RJ-45 ¦ 2 x 10GBase-X SFP+ uplink
Power
Power Device
Internal power supply
Power Consumption Operational
47 Watt
Miscellaneous
Included Accessories
Rubber feet
Rack Mounting Kit
Included
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - replacement - lifetime - response time: next business day
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
90% (non-condensing)
Min Storage Temperature
-20 °C
Max Storage Temperature
70 °C
Humidity Range Storage
95% (non-condensing)
