General
Device Type
Radio access point
Networking
Connectivity Technology
Wireless
Data Transfer Rate
3.5 Gbps
Line Coding Format
1024 QAM, OFDMA
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, 802.11ax
Frequency Band
2.4 GHz, 5 GHz
Status Indicators
Power, Boot State, status
Features
Firmware upgradable, Wireless Intrusion Detection System (WIDS), Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Maximum Ratio Combining (MRC), Wireless Intrusion Prevention System (WIPS), DiffServ Code Point (DSCP) support, Bluetooth Low Energy Beaconing, Unscheduled Automatic Power Save Delivery (U-APSD), SU-MIMO technology, AES encryption, guest access, opportunistic key caching (OKC), 4x4:4 MU-MIMO technology, packet aggregation, Orthogonal Frequency Division Multiple Access (OFDMA), Target Wait Time (TWT)
Encryption Algorithm
AES, TLS, TTLS, TKIP, WPA, WPA2-PSK, WPA2-Enterprise, WEP, EAP-SIM, WPA3-Enterprise, WPA3-Personal, WPA3-Enhanced Open
Authentication Method
MS-CHAP v.2, Extensible Authentication Protocol (EAP)
Compliant Standards
IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.3at, IEEE 802.11r, IEEE 802.11u, IEEE 802.11ac Wave 2, IEEE 802.11ax
Aerial
Expansion / Connectivity
Interfaces
1 x 1/2.5GBase-T (PoE+) - RJ-45
Miscellaneous
Included Accessories
Mounting kit
Compliant Standards
CSA, VCCI, ICES-003, EN55024, CISPR 22, FCC Part 15 B, RSS-102, UL 2043, RoHS, FCC Part 2, AS/NZS 4268, FCC Part 15 E, FCC CFR47 Part 15 C, EN 62311, EN 300 328, EN 50385, RSS-247, EN 301 489-1-17, EN 62479, EN 301 893, EN 55032, AS/NZS 2772, CB 60950, CB 62368, IFT, NOM-208, NCC LP0002
Power
Power Over Ethernet (PoE) Supported
PoE+
Power Device
External power adapter
Voltage Required
DC 12 V (non-PoE) / 42.5 - 57 V (PoE+)
Power Consumption Operational
18 Watt
Manufacturer Warranty
Service & Support
Limited warranty - replacement - lifetime
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
