General
Device Type
Radio access point
Networking
Connectivity Technology
Wireless
Data Transfer Rate
1733 Mbps
Line Coding Format
CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Spread Spectrum Method
OFDM, DSSS
Frequency Band
2.4 GHz, 5 GHz
Performance
Maximum data rate (2.4 GHz): 300 Mbps
Maximum data rate (5 GHz): 1.733 Gpps
Capacity
Wireless clients per Wi-Fi radio: 256
BSSIDs per radio: 16
Status Indicators
System, status
Features
Firewall protection, auto-uplink (auto MDI/MDI-X), DFS support, Mesh networking, IPSec Virtual Private Network (VPN), Quality of Service (QoS), Trusted Platform Module (TPM), reset button, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Direct Sequence Spread Spectrum (DSSS), Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), security lock slot (cable lock sold separately), Advanced Cellular Coexistence (ACC), ClientMatch, cyclic shift diversity (CSD), AppRF technology, Bluetooth Low Energy Beaconing, Aruba Beacons Bluetooth Low-Energy (BLE) technology, Reputation Enabled Defense, packet aggregation A-MPDU, packet aggregation A-MSDU, wireless intrusion protection, Air Monitor (AM), Dynamic Frequency Selection (DFS), IP Security (IPSec) support, 4x4 MU-MIMO technology, Energy-Efficient Ethernet (EEE), quad-stream (4x4), Orthogonal Frequency Division Multiplexing (OFDM), Aruba AirMatch
Compliant Standards
IEEE 802.3at, IEEE 802.3az
Aerial
Antenna
External detachable
Directivity
Omni-directional
Internet of Things (IoT)
Communications Technology
Bluetooth Low Energy (LE)
Expansion / Connectivity
Interfaces
1 x 1000Base-X - SFP (mini-GBIC)
1 x 1000Base-T - RJ-45
1 x micro-USB
Miscellaneous
Compliant Standards
CB, UL 2043, FCC, cTUVus, IP67, IP68, EN 60601-1-1, LVD 2014/35/EU, Directive 2014/30/EU, ISED, Directive 2014/53/EU, IEC/EN/UL 60950, EN60601-1-2
Power
Power Over Ethernet (PoE) Supported
PoE+
Power Consumption Operational
23 Watt
Software / System Requirements
OS Required
ArubaOS, InstantOS
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
65 °C
Humidity Range Operating
5 - 95% (non-condensing)
