General
Device Type
Network management device
Built-in Devices
Status LCD
Networking
Form Factor
Rack-mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Performance
Firewall throughput: 20 Gbps
Capacity
Maximum number of access points: 512 ¦ Concurrent devices: 16384 ¦ Virtual interfaces (VLANs): 4094 ¦ Concurrent GRE tunnels: 8192 ¦ Maximum RAPs: 512 ¦ Concurrent tunneled ports: 8192 ¦ Concurrent IPSec sessions: 16384 ¦ Concurrent SSL fallback sessions: 8192 ¦ Active firewall sessions: 2015291
Status Indicators
Status, link/activity
Features
Layer 3 switching, VPN support, IPv6 support, IPv4 support, Adaptive Radio Management (ARM), AppRF technology
Expansion / Connectivity
Interfaces
4 x 10GBase-X - SFP+ ¦ 2 x 1000Base-X ¦ 1 x USB 2.0 ¦ 1 x console - RJ-45 ¦ 1 x mini-USB
Miscellaneous
Compliant Standards
C-Tick, CISPR 22 Class B, EN 61000-3-2, NOM, EN 61000-3-3, EN55022 Class B, CB, ICES-003 Class B, FCC Part 15 B, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, MIC, AS/NZS 3548, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1 Second Edition, KCC, ANATEL, cTUVus, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class B, KN24, EN 55024: CISPR 24:2010
Pricing Type
K-12 education
Power
Power Device
Internal power supply - hot-plug
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
110 Watt
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 1 year ¦ New releases update - 90 days
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
