General
Device Type
Switch - 12 ports - L2+ - smart - stackable
Enclosure Type
Rack-mountable 1U
Subtype
10 Gigabit Ethernet
Ports
12 x 100/1000/10000 + 4 x 10 Gigabit SFP+
Performance
Latency (100 Mbps): 7.4 µs
Latency (1 Gbps): 4.2 µs
Latency (10 Gbps): 1.1 µs
Throughput: 238 Mpps
Switching capacity: 320 Gbps
Capacity
IPv4 routing table entries: 512
IPv6 routing table entries: 512
MAC Address Table Size
16000 entries
Jumbo Frame Support
9216 bytes
Routing Protocol
IGMPv2, IGMP, IGMPv3, static IPv4 routing, MLDv2, MLD
Remote Management Protocol
SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SCP, RADIUS
Authentication Method
RADIUS
Features
Flow control, auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, port mirroring, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, DHCP server, MLD snooping, TPM, Cable Diagnostics Function, DHCP relay, Port Security, port based access control, DHCP client, Energy Efficient Ethernet, CoS, cloud managed, IP source guard, ICMP, dual image support, DNS client, LLDP-MED, ingress rate limiting, protected ports, BPDU Filter, WRR, ARP filtering, DSCP prioritisation, auto voice VLAN, loop protection
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1t, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az
Status Indicators
Port status
Expansion / Connectivity
Interfaces
12 x 10Gbit LAN RJ-45
4 x 10Gbit LAN SFP+
Power
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Operational
80 Watt
Miscellaneous
Rack Mounting Kit
Included
Compliant Standards
Plug and Play, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3, ICES-003 Class A, VCCI Class A, IEC 60825-1 Class 1, FCC CFR47 Part 15 A, CNS 13438 Class A, KN35, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, AS/NZS CISPR 32 Class A, KN32 Class A, EN 62368-1, IEC 62368-1, IEC/EN 61000-4-11, IEC/EN 61000-4-2, EN 62368-1 Second Edition, UL 62368-1 Second Edition, IEC/EN60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013, EN 60825-1 Class 1, CAN/CSA-C22.2 No. 62368-1, UL 62368-1, EN 55035, EN 55032/CISPR 32 Class A, CISPR 35, IEC 62368-1 Second Edition, UL 62368-1 Third Edition, EN 62368-1 Third Edition, IEC 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1 Second Edition
Localisation
English / Europe
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
Technical support - live chat - lifetime
Technical support - phone consulting - 90 days from date of purchase
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
15 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
15 - 95% (non-condensing)
