General
Device Type
Switch - 24 ports - Managed
Enclosure Type
Rack-mountable 1U
Performance
Routing/switching capacity: 160 Gbps
Switching fabric bandwidth: 169 Gbps
Latency (1 Gbps): 2.8 µs
Latency (10 Gbps): 1.8 µs
Throughput (64-byte packet size): 95.2 Mpps
Capacity
Routing tables: 10000
MAC Address Table Size
64K entries
Routing Protocol
OSPF, BGP-4, RIP-1, RIP-2, BGP, OSPFv2, OSPFv3
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, SSH-2, XRMON
Authentication Method
RADIUS, TACACS+
Features
Flow control, full duplex capability, DHCP support, BOOTP support, VLAN support, Syslog support, DiffServ support, sFlow, Multiple Spanning Tree Protocol (MSTP) support, Quality of Service (QoS), Jumbo Frames support, LLDP support, Link Aggregation Control Protocol (LACP)
Compliant Standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1AX
Expansion / Connectivity
Interfaces
24 x 1000Base-T RJ-45
1 x network stack device
1 x console RJ-45
1 x management (LAN) RJ-45
1 x
Expansion Slots
1 (total) / 1 (free) x Expansion Slot
Power
Power Device
Internal power supply - hot-plug
Installed Qty
1 (installed) / 2 (max)
Power Redundancy Scheme
1+1 (with optional power supply)
Miscellaneous
Included Accessories
Fan tray
Compliant Standards
FCC Class A certified, CISPR 22 Class A, EN 60950, EN55022, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-8, IEC 60950, UL 60950, UL 60950-1, EN 60825, EN 61000-3-3:2008, CAN/CSA C22.2 No. 60950, EN 61000-3-2:2006+A1:2009+A2:2009, VCCI Class A, EN 55024:2010, EN 55022:2010, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+AC:2013, CAN/CSA-C22.2 No. 60950-1
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
15 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
15 - 90% (non-condensing)
