General
Device Type
Switch - Managed
Enclosure Type
Rack-mountable 4U
Power Over Ethernet (PoE)
PoE+
Performance
Throughput: 392.8 Mbps
Routing/switching capacity: 528 Gbps
Switching fabric bandwidth: 1015 Gbps
Capacity
IPv4 routing table entries: 10000
IPv6 routing table entries: 5000
MAC Address Table Size
64K entries
Routing Protocol
OSPF, RIP-1, RIP-2, BGP, IGMP, OSPFv2, static IP routing, IGMPv3, OSPFv3
Remote Management Protocol
SNMP 1, RMON 2, RMON, SNMP 3, SNMP 2c, HTTP, SSH-2, CLI, XRMON
Authentication Method
RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Features
VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, half duplex mode, full duplex mode, sFlow, VRRP support, ACL support, QoS, MLD snooping, STP Root Guard, UDLD, Rapid PVST+, LLDP support, Port Security, DHCP protection, CoS, sFlow v5, GARP, ToS
Compliant Standards
IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
Expansion / Connectivity
Expansion Slots
6 (total) / 6 (free) x Expansion Slot
Power
Power Device
Internal power supply (not installed)
Miscellaneous
Included Accessories
Fan tray
Rack Mounting Kit
Included
Compliant Standards
FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 60950, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 60950, EN 61000-3-3, EN55024, UL 60950, CSA 22.2 No. 60950, FCC Part 15, EN 61000-4-11, EN 55022 Class A
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - replacement - lifetime - response time: next business day
Technical support - phone consulting - lifetime
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
15 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
15 - 95% (non-condensing)
