General
Device Type
Switch - 16 ports - unmanaged
Enclosure Type
Desktop, wall-mountable
Ports
16 x 10/100/1000 (PoE+)
Power Over Ethernet (PoE)
PoE+
Performance
Non-blocking bandwidth: 32 Gbps ¦ Packet buffer size: 1 MB ¦ Forwarding performance (64-byte packet size): 1448000 pps ¦ Latency (64-byte packets): 3.7 µs
MAC Address Table Size
4K entries
Jumbo Frame Support
9216 bytes
Features
Auto-negotiation, auto-uplink (auto MDI/MDI-X), DiffServ support, half duplex mode, full duplex mode, fanless, Energy Efficient Ethernet, Class of Service (CoS), SOHO (Small Office/Home Office), Weighted Round Robin (WRR)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3at, IEEE 802.3az
Status Indicators
Power, PoE, fan, link/activity/speed
Expansion / Connectivity
Interfaces
16 x 1000Base-T RJ-45 PoE+ - 30 W
Power
Power Device
External power adapter
Power Consumption Operational
195.9 Watt
Power Consumption Stand by
2.67 Watt
Miscellaneous
Included Accessories
Wall mounting kit
Compliant Standards
Plug and Play, VCCI, CB, IC Class A, FCC Part 15 A, LVD, KC, RCM
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - 3 years ¦ Limited warranty - phone consulting - 90 days
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
90% (non-condensing)
Min Storage Temperature
-20 °C
Max Storage Temperature
70 °C
Humidity Range Storage
95% (non-condensing)
