General
Device Type
Switch - 24 ports - smart
Enclosure Type
Desktop, rack-mountable
Ports
24 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP (uplink)
Power Over Ethernet (PoE)
PoE+
Performance
Switching capacity: 52 Gbps ¦ Forwarding rate: 38.7 Mpps ¦ Packet buffer size: 525 KB
MAC Address Table Size
8K entries
Routing Protocol
IGMPv2, IGMP, IGMPv3, RSTP, STP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, SSH, CLI, NTP, ICMP, DHCP, RSTP, RADIUS
Features
Flow control, IGMP snooping, Syslog support, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Weighted Fair Queuing (WFQ), DHCP snooping, LLDP support, DHCP relay, Link Aggregation Control Protocol (LACP), DHCP client, Management Information Base (MIB), dual firmware images, Strict Priority Queuing (SPQ), Neighbor Discovery Protocol (NDP), port isolation, Class of Service (CoS), 8KV/15KV ESD Protector, DiffServ Code Point (DSCP) support, IGMP filtering, CPU protection, 4KV Surge protection, Loop Guard, LLDP-MED, Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), VLAN trunking, security slot (Kensington security lock compatible)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
Expansion / Connectivity
Interfaces
24 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-T / 1000Base-X RJ-45/SFP uplink
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
448.9 Watt
Miscellaneous
Rack Mounting Kit
Included
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
-20 °C
Max Operating Temperature
50 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 95% (non-condensing)
