General
Device Type
Switch - 5 ports - Managed
Ports
1 x 10/100/1000 + 4 x 10/100/1000 (PoE+)
Power Over Ethernet (PoE)
PoE+
Performance
Switching capacity: 10 Gbps
Capacity
Multicast groups: 128
MAC Address Table Size
2000 entries
Routing Protocol
IGMPv2, IGMPv3, IGMP
Remote Management Protocol
HTTP
Features
QoS, IGMP snooping, Broadcast Storm Control, VLAN support, flow control, firmware upgradable, 128KB packet buffer, Energy Efficient Ethernet, tagged VLAN, auto-uplink (auto MDI/MDI-X), store and forward, CoS, LDF support, port mirroring, Link Aggregation, fanless, WRR, metal housing, wall mountable
Compliant Standards
IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.1Q
Built-in Devices
Power on/off switch
Status Indicators
Power, PoE, port status
Expansion / Connectivity
Interfaces
4 x 1000Base-TX RJ-45 PoE+ - 30 W
1 x 1000Base-TX RJ-45
Power
Power Device
External power adapter
Power Consumption Operational
72 Watt
Miscellaneous
Compliant Standards
BSMI, FCC, EMC Class B, LVD
Dimensions & Weight
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
10 - 90% (non-condensing)
