General
Device Type
Radio access point
Networking
Form Factor
Wall / ceiling mountable
Connectivity Technology
Wireless
Line Coding Format
OFDM, 1024 QAM, OFDMA
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
Spread Spectrum Method
OFDM, OFDMA
Remote Management Protocol
SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, NTP
Frequency Band
2.4 GHz, 5 GHz
Performance
Maximum data rate (2.4 GHz): 574 Mbps
Maximum data rate (5 GHz): 2402 Mbps
Bandwidth: 160 MHz
Capacity
Maximum number of configured SSIDs: 16
Number of concurrent clients: 250+
Features
Load balancing, VLAN support, Syslog support, E-mail alert, MAC address filtering, Wi-Fi Multimedia (WMM) support, Access Control List (ACL) support, Quality of Service (QoS), reset button, Captive Portal, Transmit Power Control (TPC), MU-MIMO technology, beamforming technology, band steering, SSID to VLAN mapping, rate limit, Wireless Scheduler, wireless SSID, LED on/off button, seamless roaming, Airtime Fairness, Zero-touch provisioning (ZTP), adjustable transmission power, schedule reboot, self-healing network, Omada Mesh technology, multi-site management
Encryption Algorithm
WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise, WPA3-Personal, WPA2-Personal, WPA-Personal
Authentication Method
Secure Shell (SSH), Radio Service Set ID (SSID)
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Aerial
Directivity
Omni-directional
Expansion / Connectivity
Interfaces
1 x 1000Base-T (PoE+) - RJ-45
Miscellaneous
Included Accessories
Wall/ceiling mounting kit
Compliant Standards
FCC, RoHS
Power
Power Over Ethernet (PoE) Supported
PoE+
Power Device
External power adapter
Power Consumption Operational
14.7 Watt
Software / System Requirements
Software Included
Omada Controller
OS Required
Linux, Windows 8, Microsoft Windows XP / Vista / 7 / 10 / 11
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% RH (non-condensing)
