General
Packaged Quantity
5 (specifications are for single item)
Device Type
Radio access point
Networking
Form Factor
Wall / ceiling mountable
Connectivity Technology
Wireless
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Network / Transport Protocol
HTTP, HTTPs
Remote Management Protocol
SNMP 1, SNMP 2c, HTTP, HTTPS, SSH
Frequency Band
2.4 GHz, 5 GHz
Performance
Maximum throughput (2.4 GHz): 450 Mbps
Maximum throughput (5 GHz): 1300 Mbps
Features
Syslog support, E-mail alert, MAC address filtering, Wi-Fi Multimedia (WMM) support, rogue access point detection, Captive Portal, security lock slot (cable lock sold separately), 802.1x authentication, Transmit Power Control (TPC), MU-MIMO technology, beamforming technology, band steering, SSID to VLAN mapping, rate limit, Wireless Scheduler, seamless roaming, Airtime Fairness, Zero-touch provisioning (ZTP), schedule reboot, load balance network mode, Omada Mesh technology, secure guest network
Encryption Algorithm
128-bit WEP, 64-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2-PSK, WPA2-Enterprise
Authentication Method
Secure Shell (SSH)
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.11k, IEEE 802.3at, IEEE 802.11ac, IEEE 802.11v
Aerial
Directivity
Omni-directional
Expansion / Connectivity
Interfaces
1 x 1000Base-T (PoE) - RJ-45
1 x 1000Base-T - RJ-45
Miscellaneous
Included Accessories
Wall/ceiling mounting kit
Compliant Standards
FCC, RoHS
Power
Power Over Ethernet (PoE) Supported
PoE
Power Consumption Operational
12.3 Watt
Software / System Requirements
OS Required
Linux, Microsoft Windows XP / Vista / 7 / 8 / 10
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
