General
Enclosure Type
Desktop - modular - 3U
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Capacity
Cisco Unified Communications Manager Express sessions: 350
Cisco Unified SRST sessions: 1200
Network / Transport Protocol
IPSec, PPPoE, L2TPv3
Routing Protocol
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR)
Remote Management Protocol
SNMP, RMON
Features
Firewall protection, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, CBWFQ, WRED, QoS, DMVPN
Compliant Standards
IEEE 802.3, IEEE 802.1Q, IEEE 802.1ah, IEEE 802.1ag, CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, AS/NZ 3548 Class A, CAN/CSA-E60065-00, ICES-003 Class A, CS-03, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60065, BSMI CNS 13438, EN 300 386
RAM
1 GB (installed) / 2 GB (max)
Flash Memory
256 MB (installed) / 8 GB (max)
Status Indicators
Power, link/activity
Expansion / Connectivity
Interfaces
3 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Management: 1 x console - RJ-45
Management: 1 x console - mini-USB Type B
Serial: 1 x auxiliary - RJ-45
USB 2.0: 2 x 4 pin USB Type A
2 x SFP (mini-GBIC)
Expansion Slots
4 (total) / 4 (free) x EHWIC
4 (total) / 4 (free) x PVDM
2 (total) / 1 (free) x CompactFlash
1 (total) / 1 (free) x expansion slot
4 (total) / 4 (free) x service module (SM)
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V (47/63 Hz)
Software / System Requirements
OS Provided
Cisco IOS IP Base
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - 90 days
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 85%
