General
Enclosure Type
Desktop - modular - 1U
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol
IPSec
Routing Protocol
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing
Remote Management Protocol
SNMP, RMON
Features
MPLS support, Syslog support, IPv6 support, CBWFQ, WRED
Compliant Standards
IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag, CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, CAN/CSA-E60065-00, ICES-003 Class A, CS-03, AS/NZS 3548, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60065, BSMI CNS 13438, EN 300 386
RAM
512 MB (installed) / 2 GB (max)
Flash Memory
256 MB (installed) / 8 GB (max)
Status Indicators
Power, link/activity
Expansion / Connectivity
Interfaces
2 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Management: 1 x console - RJ-45
Management: 1 x console - mini-USB Type B
Serial: 1 x auxiliary - RJ-45
USB: 2 x 4 pin USB Type A
Serial: 2 x RS-232
Expansion Slots
4 (total) / 3 (free) x EHWIC
2 (total) / 2 (free) x PVDM
2 (total) / 1 (free) x CompactFlash
1 (total) / 1 (free) x ISM
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Miscellaneous
Cables Included
2 x serial cable - 3 m
Rack Mounting Kit
Included
Software / System Requirements
Software Included
Cisco IOS IP Base
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 85%
