General
Device Type
Switch - 16 ports - unmanaged
Enclosure Type
Desktop, rack-mountable, wall-mountable
Ports
8 x 10/100/1000 (PoE) + 8 x 10/100/1000
Power Over Ethernet (PoE)
PoE
Performance
Forwarding performance (64-byte packet size): 23.8 Mpps ¦ Switching capacity: 32 Gbps
Capacity
Buffer capacity (MB): 2
MAC Address Table Size
8K entries
Jumbo Frame Support
9216 bytes
Features
Flow control, auto-uplink (auto MDI/MDI-X), Quality of Service (QoS), Cable Diagnostics Function, fanless, Energy Efficient Ethernet, Head-of-line (HOL) blocking, Weighted Round Robin (WRR), loopback detection, security slot (Kensington security lock compatible)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3az
Status Indicators
Power, PoE, link/activity
Expansion / Connectivity
Interfaces
8 x 10/100/1000 Base-T RJ-45 PoE ¦ 8 x 10/100/1000 Base-T RJ-45
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
80.38 Watt
Miscellaneous
Included Accessories
Mounting kit
Compliant Standards
FCC Class B certified, UL 60950, CSA 22.2, FCC CFR47 Part 15 A
Localisation
United Arab Emirates, Indonesia, Israel, South Africa, Vietnam, Ukraine, Egypt, Thailand, Philippines, Korea, Russia, Switzerland, Turkey, European Economic Area
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - lifetime ¦ Technical support - web support - 1 year ¦ Technical support - phone consulting - 1 year
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
Min Storage Temperature
-20 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 90% (non-condensing)
