General
Device Type
Switch - 24 ports - L3 - Managed - stackable
Enclosure Type
Rack-mountable
Subtype
10 Gigabit Ethernet
Ports
24 x 100/1000/2.5G/5G/10GBase-T (UPOE+)
Power Over Ethernet (PoE)
UPOE+
Performance
Switching capacity: 880 Gbps
Switching capacity with stacking: 1880 Gbps
Forwarding rate: 327.38 Mpps
Forwarding rate with stacking: 1398.8 Mpps
Capacity
IPv4 routing table entries: 39000
Multicast routes: 8000
QoS scale entries: 4000
ACL scale entries: 8000
IPv6 routing table entries: 19500
Packet buffer size: 16 MB
FNF entries: 64000
VLAN IDs: 4094
Switched virtual interfaces (SVIs): 1000
MAC Address Table Size
32000 entries
Jumbo Frame Support
9198 bytes
Routing Protocol
RIP, RIP-1, RIP-2, VRRP, PIM-SM, static IP routing, GRE, PIM-SSM, policy-based routing (PBR), RIPng, MSTP, STP, LISP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, HTTP, CLI, NETCONF, RESTCONF, gRPC, YANG
Encryption Algorithm
128-bit AES, 256-bit AES
Features
VPN support, full duplex mode, QoS, Cisco StackWise Technology, Rapid PVST+, SRR, LACP support, RSPAN, FNF, 802.1x authentication, DSCP support, VPLS, CoPP, EVPN, EoMPLS, Blue Beacon LED, ZTP, EEE, SPAN, PIM, FHS, PVLAN support, CIR, Cisco UADP 2.0, CDP, mDNS, SUDI, Preboot Execution Environment, Cisco StackWise-1T technology
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3an, IEEE 802.3at, IEEE 1588v2, IEEE 802.1BA, IEEE 802.3bz
Expansion / Connectivity
Interfaces
24 x 100/1000/2.5G/5G/10GBase-T RJ-45 UPOE+ - 90 W
1 x USB 2.0
Expansion Slots
1 (total) / 1 (free) x Expansion Slot
Power
Power Device
Internal power supply - hot-plug
Voltage Required
AC 115-240 V (50 - 60 Hz)
80 PLUS Certification
80 PLUS Platinum
Miscellaneous
Compliant Standards
EN 61000-3-2, EN 61000-3-3, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, CNS 13438, EN 300 386 V1.6.1, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, EN 55035, CISPR 35, V-2/2015.04, V-3/2015.04
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - replacement - lifetime - response time: next business day
Technical support - consulting - 90 days
Environmental Parameters
Min Operating Temperature
-5 °C
Max Operating Temperature
45 °C
Humidity Range Operating
5 - 90% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 90% (non-condensing)
