Cisco Catalyst 9300L Mini - Network Essentials

Productcode: C9300LM-48U-4Y-E | EAN/UPC: 0889728429832

€ 8.071,39 excl.btw

Cisco Catalyst 9300L Mini - Network Essentials - switch - L3 - Managed - 48 x 10/100/1000 (UPOE) + 4 x 25 Gigabit SFP (uplink) - rack-mountable - UPOE

High wireless scale for Wi-Fi 6 and 802.11ac Wave 2 access points supported
Catalyst 9300L models are based on the Cisco UADP 2.0 Application-Specific Integrated Circuit (ASIC) with programmable pipeline and micro-engine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries
x86 CPU complex with a large memory, and the flash and external USB 3.0 SSD pluggable storage slot
USB 2.0 slot to load system images and set configurations
Flexible and dense uplink offerings with 100G, 40G, 25G, Multigigabit, 10G, and 1G as fixed or modular uplinks
Easy transition from 40G to 100G and 10G to 25G with dual-rate optics
With a mix of Copper (1G up to 10G) and Fiber (1G up to 25G) supported in a single stack, multiple flexible deployment scenarios are enabled, including 2-Tier, 3-Tier and Hybrid architectures
PoE capabilities with up to 384 ports of PoE per stack, PoE+, and 288 ports high density IEEE 802.3bt - 90W UPOE+, and 60W Cisco UPOE
Intelligent Power Management with Cisco StackPower technology, providing power stacking among members for power redundancy. StackPower pools the power supplies across the stack to be used redundancy and supplemental power purposes
Line-rate, hardware-based Flexible NetFlow (FNF), delivering flow collection of up to 128,000 flows with select models
IPv6 support in hardware, providing wire-rate forwarding for IPv6 networks
Dual-stack support for IPv4/IPv6 and dynamic hardware forwarding table allocations, for ease of IPv4-to-IPv6 migration
Support for both static and dynamic NAT and Port Address Translation (PAT)
IEEE 802.1ba AV Bridging (AVB) built in to provide a better audio and video experience through improved time synchronization and QoS

Op voorraad: 6 stuk(s)

Levertijd:

Product:
Cisco Catalyst 9300L Mini - Network Essentials

€ 9766,38 incl. 21% btw € 8071,39excl. 21% btw

Winkelwagen Offerte

Omschrijving

Cisco Catalyst 9300L Mini - Network Essentials - switch - L3 - Managed - 48 x 10/100/1000 (UPOE) + 4 x 25 Gigabit SFP (uplink) - rack-mountable - UPOE

Product features

Advanced security
With 128-bit and 256-bit AES encryption, the Cisco Catalyst 9300L Mini ensures secure data transmission across the network, providing peace of mind for sensitive information handling.
High capacity and performance
Boasting a stacking bandwidth of 320 Gbps and support for up to 32,000 IPv4 routes, this switch is designed to handle heavy data loads with ease, ensuring smooth and efficient network operation.
Robust environmental adaptability
Operational in a wide range of temperatures from -5°C to 45°C and humidity levels from 5 - 90% (non-condensing), the Cisco Catalyst 9300L Mini is built to withstand challenging environmental conditions.
Comprehensive networking features
Features such as Access Control List (ACL) support, Cisco StackWise-320 technology, and Quality of Service (QoS) make this switch highly versatile for managing complex network architectures.
Efficient manageability
Remote management protocols including SNMP, NETCONF, and RESTCONF, along with Cisco's intuitive management tools, provide streamlined configuration and monitoring for optimized network performance.

Specificaties

General

Device Type

Switch - 48 ports - L3 - Managed - stackable

Enclosure Type

Rack-mountable

Subtype

Gigabit Ethernet

Ports

48 x 10/100/1000 (UPOE) + 4 x 25 Gigabit SFP (uplink)

Power Over Ethernet (PoE)

UPOE

Performance

Stacking bandwidth: 320 Gbps
Switching capacity: 296 Gbps
Switching capacity with stacking: 616 Gbps
Forwarding rate: 220.22 Mpps
Forwarding rate with stacking: 458.3 Mpps

Capacity

IPv4 routes: 32000
IPv6 routes: 16000
Multicast scale: 8000
QoS scale entries: 5120
ACL scale entries: 5120
Buffer capacity (MB): 16
FNF entries: 64000
VLAN IDs: 4094
Switched virtual interfaces (SVIs): 1000
Routed ports: 416
OSPF routes: 1000

MAC Address Table Size

32000 entries

Jumbo Frame Support

9198 bytes

Max Units In A Stack

Routing Protocol

OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, gRPC, IPv4, IPv6, YANG

Encryption Algorithm

128-bit AES, 256-bit AES

Features

ACL support, QoS, Cisco StackWise Technology, Rapid PVST+, SRR, RSPAN, NetFlow, CoS, FNF, DSCP support, hot swappable 3 fans, built-in ASIC, CoPP, SDN, Blue Beacon LED, ZTP, secure boot, EEE, SPAN, PIM, FHS, PVLAN support, CIR, MACsec, Cisco IP SLA, Cisco Trust Anchor module, Cisco UADP 2.0, Cisco StackWise-320 technology, CDP, Preboot Execution Environment

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3an, IEEE 802.3at, IEEE 1588v2, IEEE 802.1BA, IEEE 802.3bz, IEEE 802.3bt, Wi-Fi CERTIFIED 6

RAM

8 GB

Flash Memory

16 GB

Status Indicators

Status

Expansion / Connectivity

Interfaces

48 x 1000Base-T RJ-45 UPOE - 60 W
4 x 25GBase-X SFP uplink
Network stack device
1 x management (LAN) RJ-45
1 x console
1 x USB 2.0

Power

Power Device

Internal power supply - hot-plug

Installed Qty

Max Supported Qty

Power Redundancy

Optional

Power Provided

1000 Watt

Voltage Required

AC 100-240 V (50 - 60 Hz)

Miscellaneous

MTBF

304,970 hours

Compliant Standards

Plug and Play, EN 61000-3-2, EN 61000-3-3, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, CNS 13438, EN 300 386 V1.6.1, EN 300 386, KN32, KN35, ETA, EN 55032 Class A, CISPR 32 Class A, VCCI-CISPR 32:2016 Class A, TCVN 7189 Class A, V-3 Class A, TCVN 7317, EN 55035, CISPR 35, AN/NZS 60950.1, V-2/2015.04, V-3/2015.04, QCVN 118:2018, CAN/CSA C22.2 No. 60950-1

Software / System Requirements

Software Included

Cisco IOS XE 17.9 Universal

Dimensions & Weight

Width

44.4 cm

Depth

33.4 cm

Height

4.3 cm

Weight

5.45 kg

Manufacturer Warranty

Service & Support

Limited warranty - advance hardware replacement - lifetime - response time: next business day
Technical support - consulting - 90 days

Environmental Parameters

Min Operating Temperature

-5 °C

Max Operating Temperature

45 °C

Humidity Range Operating

5 - 90% (non-condensing)

Min Storage Temperature

-40 °C

Max Storage Temperature

70 °C

Humidity Range Storage

5 - 90% (non-condensing)

This data is supplied by 1WorldSync and matched through an automated process. Truedata is not responsible for errors in this data.
