General
Device Type
Router - 4-port switch (integrated)
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol
L2TP, RSVP, ICMP/IP, IPSec, FTP, DHCP, DNS, L2TPv3, DDNS, RTP, HTTP, HTTPs, cRTP
Routing Protocol
OSPF, RIP-1, RIP-2, BGP, EIGRP, HSRP, VRRP, NHRP, IGMPv3, GRE, OSPFv3, policy-based routing (PBR), BGP-4+, WCCP, Bidirectional Forwarding Detection (BFD), RSVP, STP, MGRE
Remote Management Protocol
Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI
Encryption Algorithm
DES, Triple DES, AES, SSL, PKI, 128-bit AES, 192-bit AES, 256-bit AES
Authentication Method
Secure Shell (SSH), RADIUS, TACACS+
Features
NAT support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DiffServ support, MAC address filtering, LLQ, CBWFQ, WFQ, ACL support, QoS, LFI, DMVPN, DHCP server, VRF-Lite, DNS proxy, DHCP relay, DHCP client, MIB, NDP, VPN Server, FNF, DSCP support, Storm Control, SmartPort technology, VPN client, HQoS, SPAN, EEM, MHSRP, NBAR, NBAR 2, PfR, CBTS, CBTP, CBWRED, Cisco IP SLA, Cisco NG PnP Protocol
Compliant Standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, EN 61000-6-1, AS/NZS 60950-1, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, VCCI V-3, KN24, EN 55024:2010, CNS13438:2006, EN 61000-3-2:2006, EN 61000-3-3:2008, EN 300 386 V1.6.1, CISPR 24:2010, CISPR 22:2008, TCVN 7189, EN 55032, CAN/CSA-C22.2 No. 60950-1, TCVN 7317, KN22:2009, ICES-003:2012 Issue 5, EN 300 386
Communications
Type
Wireless cellular modem
Mobile Communication Protocol
HSPA+, LTE, FDD LTE
Expansion / Connectivity
Interfaces
WAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45
LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Management: 1 x console - RJ-45
USB 2.0: 1 x 4 pin USB Type A
Expansion Slots
1 (total) / 1 (free) x SIM
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Miscellaneous
Software / System Requirements
OS Provided
Cisco IOS IP Base
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - advance parts replacement - 1 year - response time: 10 days
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
5 - 95% (non-condensing)
