General
Enclosure Type
Rack-mountable - 2U
Connectivity Technology
Wired
Data Link Protocol
Gigabit Ethernet
Performance
SD-WAN IPsec throughput (1400Bytes, clear text): up to 1.9 Gbps
SD-WAN IPsec throughput (IMIX, clear text): 1.75 Gbps
IPv4 forwarding throughput (1400-byte packet size): 19.7 Gbps
IPsec throughput (1400Bytes, clear text): up to 1.9 Gbps
Capacity
SD-WAN overlay tunnels scale: 6000
IPsec SVTI tunnels: 4000
ACL: 4000
Access Control Entries (ACEs) per system (IPv4): 72000
IPv4 routes: 1600000
IPv6 routes: 1500000
Queues: 16000
NAT sessions: 1200000
Firewall sessions: 512000
Virtual Routing and Forwarding (VRF) entries: 4000
Network / Transport Protocol
IPSec, IPv4, IPv6, RSVP, DHCP, DNS, L2TPv3, PPPoE, RTP, RTCP, NTP
Routing Protocol
Static IP routing, RIP-1, RIP-2, OSPF, EIGRP, BGP, IS-IS, IGMPv3, PIM-SM, PIM-SSM, RSVP, LISP, HSRP, Bidirectional Forwarding Detection (BFD), GRE, policy-based routing (PBR), VRRP, MPLS, OSPFv3, DVMRP
Remote Management Protocol
DHCP, RADIUS, OMP, SNMP, NTP, SSH, SCP, NETCONF, CLI
Encryption Algorithm
SSL, IKE, DES, 128-bit AES, 256-bit AES, Triple DES, 1024-bit RSA, 2048-bit RSA, 748-bit RSA, ECDSA 256-bit, ECDSA 384-bit, MD5, SHA, 256-bit SHA, 384-bit SHA, 512-bit SHA, DTLS, TLS, PKI, HMAC, ESP, SHA-1, SHA-2, 256-bit AES-CBC, 256-bit AES-GCM
Authentication Method
RADIUS, Secure Shell (SSH)
Features
SD-WAN support, SUDI, QoS, firewall protection, NAT support, NBAR, FNF, Cisco UADP, ERSPAN, Cisco IPSLA, EEM, ACL support, EVC, AAA, AVC, PPP, MLPPP, MLFR, HDLC, CBWFQ, WRED, PfR, CAC, IVR, SAF, AAR, DNS client, DHCP client, PAT support, DHCP server, Syslog support, IPFIX, NTP server, FEC
Compliant Standards
IEEE 802.1ag, IEEE 802.3ah, IEEE 802.1Q, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, IEC/EN 60825, FDA, AS/NZS CISPR 32 Class A, CISPR 32 Class A, CNS 13438 Class A, EN 300 386, EN 55032, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN55024, FCC CFR47 Part 15 B Class A, ICES-003 Class A, IEC 61000-3-2, IEC 61000-3-3, IEC/EN 61000-4-11, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, KN32 Class A, KN35
RAM
8 GB (installed) / 32 GB (max)
IP Telephony
Expansion / Connectivity
Interfaces
WAN / LAN: 6 x 1000Base-T
USB: 1 x
Expansion Slots
2 (total) / 2 (free) x service module (SM)
2 (total) / 2 (free) x NIM
1 (total) / 1 (free) x Pluggable Interface Module (PIM)
Installed Modules Qty (Max)
0 (installed) / 5 (max)
Power
Power Device
Internal power supply
Miscellaneous
Software / System Requirements
OS Required
Cisco IOS XE 17.3.2
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 85% (non-condensing)
Compatibility Information
Designed For
P/N: C8300-DNA, UCS-E1100D-M6
