General
Enclosure Type
Rack-mountable - 1U
Connectivity Technology
Wired
Data Link Protocol
Gigabit Ethernet
Performance
IPsec throughput (1400Bytes, clear text): 1 Gbps
SD-WAN IPsec throughput (IMIX, clear text): 900 Mbps
IPv4 forwarding throughput (1400-byte packet size): 6 Gbps
Capacity
SD-WAN overlay tunnels scale: 4000
IPsec SVTI tunnels: 4000
Access Control Entries (ACEs) per system (IPv4): 72000
IPv4 routes: 1600000
IPv6 routes: 1500000
Queues: 16000
NAT sessions: 1200000
Firewall sessions: 512000
Virtual Routing and Forwarding (VRF) entries: 4000
Network / Transport Protocol
IPSec, NTP, DNS, DHCP, RSVP, RTCP, PPPoE, L2TPv3
Routing Protocol
Policy-based routing (PBR), GRE, OSPF, BGP, VRRP, MPLS, OSPFv3, RIP, RIP-2, EIGRP, IS-IS, IGMPv3, HSRP, DVMRP, Bidirectional Forwarding Detection (BFD)
Remote Management Protocol
OMP, SNMP, SCP
Encryption Algorithm
PKI, 256-bit AES-CBC, 256-bit AES-GCM, IKE, 2048-bit RSA, ECDSA 256-bit, ECDSA 384-bit, ESP, HMAC, SHA-1, SHA-2, TLS, DES, 1024-bit RSA, 128-bit AES, 256-bit SHA, 384-bit SHA, 512-bit SHA, 748-bit RSA, MD5, Triple DES
Authentication Method
Secure Shell (SSH), RADIUS
Features
URL filtering, AAA, QoS, CoS, FEC, HQoS, WRED, FNF, NBAR, AAR, DTLS, DHCP client, DHCP server, Syslog support, NAT support, PAT support, ACL support, BFD, CAC, IVR, SAF, CBWFQ, HDLC, MLFR, MLPPP, PPP, PIM, SSM, ERSPAN, Cisco IPSLA, EEM, EVC, AVC, SUDI
Compliant Standards
IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3ah, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, IEC/EN 60825, FDA, FCC CFR47 Part 15 A, ICES-003 Class A, AS/NZS CISPR 32 Class A, CISPR 32 Class A, VCCI-CISPR 32:2016 Class A, CNS 13438 Class A, EN 61000-3-2, IEC 61000-3-2, KN32 Class A, IEC/EN 61000-3-3, EN 300 386, EN 55032, EN 55035, EN 61000-6-1, EN55024, IEC/EN 61000-4-11, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, KN35
RAM
8 GB (installed) / 32 GB (max)
IP Telephony
Expansion / Connectivity
Interfaces
WAN: 4 x Ethernet 1000
Expansion Slots
1 (total) / 1 (free) x NIM
1 (total) / 1 (free) x Pluggable Interface Module (PIM)
Installed Modules Qty (Max)
0 (installed) / 2 (max)
Power
Power Device
Internal power supply - 100 Watt
Voltage Required
AC 120/230 V (50/60 Hz)
Miscellaneous
Software / System Requirements
OS Required
Cisco IOS XE 17.4.1
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 85% (non-condensing)
