General
Device Type
Switch - 24 ports - Managed
Enclosure Type
Desktop, rack-mountable 1U
Ports
24 x 32Gb Fibre Channel SFP+
Performance
Aggregate throughput: 2 Tbps ¦ Switching latency: 0.9 µs
Capacity
Maximum frame size: 2112 byte ¦ Frame buffers: 15360
Fibre Channel
FC-DA, FC-FS, FC-GS-4, FC-SB, FC-SB-2, FC-SB-3, FC-SW-3, FC-Tape, FC-VI, FC-SP, FCP-4, FC-BB-2, FCP, FCP-2, FC-BB-5, FC-BB-3, FC-FS-2, FC-GS-5, FC-SW-4, FCP-3, FC-LS, FC-MI-2, FC-PI-4, FC-FS-3, FC-GS-6, FC-PI-3, FC-SW-5, FC-BB-4, FC-IFR, FC-PI-5, FC-LS-2, FC-SP-2, FC-SB-4, FC-DA-2, FC-MI-3, FC-BB-6, FC-SB-5, FC-FS-4, FC-SW-6, FC-GS-7, FC-PI-6, FC-GS-8, FC-LS-3, FC-SB-6, FC-SW-7, MIB-FA
Remote Management Protocol
SNMP 1, SNMP 3, HTTP, HTTPS, SMI-S, SSH, SSH-2, CLI, SCP, SFTP
Authentication Method
RADIUS, TACACS+, LDAP, FCAP
Features
Syslog support, IPv6 support, IP address filtering, firmware upgradable, Full Fabric, event log, Access Control List (ACL) support, Quality of Service (QoS), enviromental monitoring, Forward Error Correction (FEC), Registered State Change Notification (RSCN) support, Adaptive Networking, Fabric Shortest Path First (FSPF), Fabric-Device Management Interface (FDMI), Virtual Fabric mode, Role-Based Access Control (RBAC), Dynamic path selection (DPS), Dynamic load sharing (DLS), Reliable Commit Service (RCS), Simple Name Server (SNS), Fibre Channel Authentication Protocol (FCAP), Power-on self-test (POST), Network Timing Protocol (NTP), flow mirroring, Dynamic Fabric Provisioning (DFP), traffic isolation zoning (TIZ), Rolling Reboot Detection (RRD), Advanced Zoning, In-flight Compression, Fabric Services
Expansion / Connectivity
Interfaces
24 x 4/8/10/16/32Gb Fibre Channel SFP+ ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 1 x management (RS-232) RJ-45 ¦ 1 x USB ¦ 24 x 4/8/10/16/32Gb Fibre Channel SFP+ Ports on Demand ¦ 4 x 16/32Gb Fibre Channel QSFP+ Ports on Demand
Power
Power Device
Internal power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 120/230 V (50/60 Hz)
Features
Rear-to-front airflow
Miscellaneous
Included Accessories
24 x 32Gb Fibre Channel SFP+ Short Wave Transceiver
Cables Included
1 x DB-9 to RJ-45 adapter
Rack Mounting Kit
Included
Compliant Standards
EN 60950, EN 61000-3-2, IEC 60950, EN 61000-3-3, EN55024, EN 61000-6-1, FIPS 140-2 Level 2, ICES-003 Class A, RoHS, FCC Part 15 B Class A, VCCI Class A, EN 55022 Class A, UL/CSA60950-1, AS/NZS 55022 Class A, INCITS 364-2003 + Amendment 1
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - replacement - 1 year - response time: next business day ¦ New releases update - 1 year ¦ Technical support - 1 year
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 85% (non-condensing)
Min Storage Temperature
-25 °C
Max Storage Temperature
70 °C
Humidity Range Storage
10 - 90% (non-condensing)
