General
Enclosure Type
DIN rail mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, digital input/output
Network / Transport Protocol
TCP/IP, PPTP, UDP/IP, NTP, IPSec, PPPoE, ARP, DHCP, DNS, DDNS, IPv4, IPv6
Routing Protocol
OSPF, RIP-1, RIP-2, BGP, EIGRP, NHRP, static IP routing, GRE, RIPng, RSTP
Remote Management Protocol
Telnet, HTTP, HTTPS, SSH, CLI, ICMP
Encryption Algorithm
DES, RC2, MD5, CAST5, MPPE, DH, SHA-1, 128-bit AES, 256-bit AES, IKEv2, 256-bit AES-GCM, 128-bit AES-GCM, 256-bit AES-CBC, ESP, CRL, 128-bit Blowfish, 128-bit AES-CBC, IKEv1, SHA-256, SHA-512, SHA-224, Chacha20-Poly 1305
Authentication Method
RADIUS, PAP, CHAP, X.509 certificates, MS-CHAP, MS-CHAP v.2
Features
Firewall protection, NAT support, PAT support, SNAT support, auto-uplink (auto MDI/MDI-X), packet filtering, MAC address filtering, IP address filtering, half duplex mode, full duplex mode, firmware upgradable, Dead Peer Detection (DPD), Dynamic Multipoint VPN (DMVPN), port forwarding, DHCP relay, NTP server, event notification, Pre-Shared Key (PSK), NTP client, realtime clock, Simple Certificate Enrollment Protocol (SCEP), DNAT support, secure boot, 1500V isolation, VLAN Tagging, port trunking, IP forwarding support, PPTP client, PPTP server, OpenVPN client, OpenVPN server, event functions, Received Signal Strength Indication (RSSI) support, DHCPv4 server, DHCPv6 server
Compliant Standards
IEEE 802.1Q, EN55024, FCC Part 15 B, IC, EN 61000-6-2, EN 61000-6-3, EN 61131-2, IP40, EN 60068-2-1, EN 55032 Class B, EN 62368-1, IEC 62368-1, EN 60068-2-27, EN 60068-2-6, EN 60068-2-14, IEC 61709, EN 60068-2-2, CBC, EN 60068-2-30
Status Indicators
Power, signal strength, WAN
Communications
Type
Wireless cellular modem
Mobile Communication Protocol
UMTS, HSDPA, HSUPA, HSPA, LTE
Cellular Band
LTE B2, LTE B4, LTE B12, HSPA B2, HSPA B4, HSPA B5, UMTS B2, UMTS B4, UMTS B5
Expansion / Connectivity
Interfaces
WAN / LAN: 2 x 10Base-T/100Base-TX - RJ-45 ¦ Antenna: 1 x SMA ¦ 1 x DI/DO
Expansion Slots
1 (total) / 1 (free) x Mini-SIM
Power
Voltage Required
DC 12 - 24 V
Power Consumption Operational
1.8 Watt
Miscellaneous
Localisation
Canada, United States
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
75 °C
Humidity Range Operating
0 - 95% (non-condensing)
