General
Enclosure Type
DIN rail mountable
Connectivity Technology
Wired, wireless
Data Link Protocol
Ethernet, Fast Ethernet, Modbus
Network / Transport Protocol
DHCPv4, DHCPv6, DNS, DDNS, PPPoE, IPSec, PPTP, FTP
Routing Protocol
Static IP routing, BGP, OSPF, RIP, RIP-2, RIPng, GRE
Remote Management Protocol
SNMP, HTTP, HTTPS, Telnet, SSH, CLI
Authentication Method
RADIUS
Features
SPIF, VPN support, MIMO technology, DHCP client, tagged VLAN, VLAN trunking, DHCP server, DNAT support, SNAT support, port forwarding, IP forwarding support, DNS relay, DynDNS, OpenVPN client, OpenVPN server, IP address filtering, PPTP server, DMVPN, full duplex mode, half duplex mode, auto-uplink (auto MDI/MDI-X), 1500V isolation, E-mail alert, SMS alert, SNMP trap, firmware upgradable, NTP client, NTP server, realtime clock, reset button
Compliant Standards
IP40, EN 55032 Class B, EN 61000-6-2, EN55024, EN 60950, IEC 60950, EN 62368-1, IEC 62368-1, EN 61131-2, EN 60068-2-6, EN 60068-2-27, EN 60068-2-1, EN 60068-2-2, EN 60068-2-14, EN 60068-30, FCC Part 15 Class B, IC
Status Indicators
Power, WAN, signal
Communications
Type
Wireless cellular modem
Mobile Communication Protocol
EDGE, GPRS, HSPA, HSPA+, LTE, UMTS
Max Transfer Rate
100 Mbps
Expansion / Connectivity
Interfaces
2 x DI
1 x DO
1 x RS-232 - 9 pin D-Sub (DB-9)
Antenna: 2 x SMA
5 x 10Base-T/100Base-TX - RJ-45
Expansion Slots
1 (total) / 1 (free) x Mini-SIM
Power
Voltage Required
DC 12 - 24 V
Power Consumption Operational
8 Watt
Miscellaneous
Localisation
United States, Canada
Software / System Requirements
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
-30 °C
Max Operating Temperature
75 °C
Humidity Range Operating
0 - 95% (non-condensing)
