General
Device Type
Thermal network camera
Audio Support
Yes: two-way audio capability
Camera Mount Type
Wall mount, ceiling mount, pole mount
Connectivity Technology
Wired
Camera
Type
Colour - fixed - outdoor - weatherproof
Digital Video Format
MJPEG, H.264, MPEG-4 AVC
Max Digital Video Resolution
640 x 480
Frame Rate (max)
8.3 frames per second
Features
Sharpness control, digital image rotation, brightness control, contrast control, image mirror, heater, ONVIF support, Privacy Mask Function, Electronic Image Stabilizer (EIS), Video Motion Detection Technology, password protection, Variable Bitrate (VBR), Zipstream technology
Lens Construction
Horizontal Field of View (degree)
10
Interfaces
Network Interface
Ethernet 10Base-T/100Base-TX
Network Protocols
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, IGMP, SSL, QOS
Expansion / Connectivity
Ports
LAN/power
Audio line in
Audio line out
Supported Memory Cards
microSD Card, microSDHC Card, microSDXC Card
Miscellaneous
Included Accessories
Wall mount bracket, ceiling mount bracket
Compliant Standards
CISPR 22 Class A, EN55024, EN55022 Class A, IEC 60529 IP66, IEC 60529 IP67, EN 61000-6-1, ICES-003 Class A, NEMA Type 4X, EN 61000-6-2, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, IEC 60068-2-27, IEC 60068-2-6, FCC Part 15 B Class A, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-52, EN 50121-4, IEC 62236-4, VCCI Class A, EN 50581, RCM, IEC 60950-22, EN 60950-22, UL 60950-22, IEC 60721-3-4, KN32, KN35
Power
Power Requirements
DC 8 - 28 V / AC 20 - 24 V / PoE
Software / System Requirements
Software Included
Drivers & Utilities
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
60 °C
Relative Humidity (operating)
10 - 100%
