General
Packaged Quantity
10 (specifications are for single item)
Compression Format
MPEG-4, H.264, AVC, Motion JPEG
Package Content
Terminal block
Software Included (Y)
Windows decoder 1-user licence, AXIS Face Detector, AXIS Motion Guard, AXIS Fence Guard, AXIS Loitering Guard, AXIS Video Motion Detection, AXIS People Counter
Country Kits
Argentina, Australia, China, Japan, India, Korea, Brazil, United Kingdom, United States, Europe
Compliant Standards
EN 61000-6-1, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, FCC Part 15 B Class A, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, VCCI Class A, RCM, IS13252, KN35, AS/NZS CISPR 32 Class A, KN32 Class A, BFR-free, EN 55032 Class A, IEEE 802.3af, CAN/CSA-C22.2 No. 62368-1, EN 55035, IEC/EN/UL 62368-1, IEEE 802.1x, PVC-free, NIST SP500-267, ICES-3(A)/NMB-3(A), CFR free, IEC/EN 60529 IP4X
Video Server
Features
microSD/SDHC/SDXC memory card slot, Forensic WDR, Zipstream
Networking
Network Interfaces
Ethernet 10Base-T/100Base-TX
Supported Protocols
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, SSH, QOS, CIFS, SRTP, SFTP, Zeroconf, USGv6, MQTT, CDP, Syslog
Features
Modular design, DiffServ support, IP address filtering, HDTV Compatible, 1080p resolution support, active anti tampering system, secure boot, HTTPS encryption, PoE powered, Variable Bit Rate (VBR), Brute Force Protection, password protection, digest authentication, signed firmware, barebone, Adaptive Bit Rate (ABR), Multi-Bit Rate (MBR), digital PTZ, network access control, multi-level user, signed video, Axis Edge Vault, Axis device ID, secure keystore, ONVIF Profile M, ONVIF Profile S, ONVIF Profile T, ONVIF Profile G, autotracking
Connections
Video Output Ports
HDMI x 1
Audio Input Ports
Terminal block
Audio Output Ports
Terminal block
Other Ports
RJ-45, RJ-12 x 1
Power
Power Consumption
5.2 Watt
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
-20 °C
Max Operating Temperature
50 °C
Humidity Range Operating
10 - 85% RH (non-condensing)
