General
Device Type
Network surveillance camera
Connectivity Technology
Wired
Camera
Type
Colour - Day&Night - pan / tilt / zoom - outdoor - vandal-proof
Digital Video Format
MPEG-4, MJPEG, H.264, AVC, HEVC, H.265
Max Digital Video Resolution
1920 x 1080
Exposure Range
1/2 sec - 1/111000 sec
Minimum Illumination
0.06 lux - colour - F1.36 - 30 IRE ¦ 0.001 lux - B&W - F1.36 - 30 IRE ¦ 0.09 lux - colour - F1.36 - 50 IRE ¦ 0.008 lux - B&W - F1.36 - 50 IRE ¦ 0 lux - IR
Frame Rate (max)
50 frames per second
Features
Sharpness control, digital image rotation, digital image freeze, white balance, colour control, progressive scanning, brightness control, Wide Dynamic Range (WDR), infrared cut filter, built-in IR illuminator, Electronic Image Stabilizer (EIS), Video Motion Detection Technology, password protection, shock detection, Variable Bitrate (VBR), OptimizedIR, 300 preset positions, Forensic Capture (120 dB), Zipstream technology, ONVIF (Profile S) support, ONVIF (Profile G) support, image overlay, Sharpdome technology, laser focus, exposure control, IP address filtering, tour recording, guard tour, HTTPs encryption, event tracking, auto tracking 2.0, TPM 2.0 module, ONVIF (Profile T) support, Adaptive Bitrate (ABR), Lightfinder 2.0 technology, Nadir flip, Machine learning processing unit (MLPU)
Image Sensor
Lens Construction
Focal Length
6.91 mm - 214.64 mm
Lens Iris
F/1.36-4.6 auto iris (P-Iris)
Focus Adjustment
Automatic
Horizontal Field of View (degree)
2 - 60.6
Vertical Field of View (degree)
1.1 - 36.5
Panning
Speed (degree/sec)
Up to 550
Tilting
Speed (degree/sec)
Up to 500
Interfaces
Network Interface
Ethernet 10Base-T/100Base-TX/1000Base-T
Network Protocols
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, IPv4, IPv6, Bonjour, RTCP, SMB, SSH, QOS, CIFS, SRTP, SFTP, NTCIP, USGv6, MQTT
Expansion / Connectivity
Supported Memory Cards
SD Memory Card, SDXC Memory Card, SDHC Memory Card
Miscellaneous
Included Accessories
AXIS High PoE Midspan (1 port), IP66-rated RJ45 connector kit
Compliant Standards
EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, EN 50121-4, IEC 62236-4, VCCI Class A, NEMA TS-2, IEC 60825-1 Class 1, KN35, NEMA250 Type 4X, AS/NZS CISPR 32 Class A, KN32 Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, IEC/EN/UL 60950-22, IEC/EN 62471, ISO 21207, CAN/CSA-C22.2 No. 62368-1, UL 62368-1, EN 55035, CISPR 35, IEC/EN 60529 IP66, CAN/CSA C22.2 No. 60950-22, NIST SP500-267, ICES-3(A)/NMB-3(A), IEC/EN 62262 IK10, FCC Part 15 Subpart B
Power
Power Requirements
High PoE
Power Device
Power injector - external AC 100-240 V
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
-50 °C
Max Operating Temperature
50 °C
Relative Humidity (operating)
10 - 100% (non-condensing)
