HPE Networking 12904E v2 Main Processing Unit. MAC-adrestabel: 16384 entries, Switchingcapaciteit: 184000 Gbit/s. DC voltage input: 48 - 60 V. Rack-montage, Vormfactor: 1U
Data-uitwisseling
MAC-adrestabel
16384 entries
Switchingcapaciteit
184000 Gbit/s
Protocollen
Routing protocols
BGP4, IS-IS, MPLS, OSPF, OSPFv3, RIP, RIPng
Prestatie
Frequentie van processor
1200 MHz
Energie
AC-ingangsspanning
100 - 240 V
DC voltage input
48 - 60 V
Energieverbruik opmerking
Power output: 2400W
Netvoeding voetnoot
16 power supply slots 1 minimum power supply required (ordered separately)
Overige specificaties
Latentie
Low latency under 5 microsecond latency (64-byte packets)
Afmetingen (B x D x H)
201 x 411 x 41 mm
Geheugen en processor
Quad Core MIPS64 at 1.2 GHz, 1 GB flash, 8 GB DDR2 SDRAM
Prestatiebeheer
IMC - Intelligent Management Center; Command-line interface; Out-of-band management (serial RS-232C); SNMP manager; Telnet; Terminal interface (serial RS-232C); Modem interface; IEEE 802.3 Ethernet MIB; Ethernet interface MIB
Aansluitingen
16 I/O module slots, maximum; Supports a maximum of 768 40GbE, 768 10GbE, 1/10GbE copper, 1/10GbE fiber, 1GbE fiber, or 10/100/1000 ports, or 576 100GbE ports, or a combination
Gewicht (imperiaal)
2,81 kg (6.2 lbs)
Afmetingen (B x D x H) (Brits)
200,7 x 411,5 x 40,6 mm (7.9 x 16.2 x 1.6")
Logistieke gegevens
Code geharmoniseerd systeem (HS)
85176990
