General
Device Type
Security appliance
Bundled Services
3 years FortiCare 24X7 Comprehensive Support + 3 years FortiGuard
Processor / Memory / Storage
Processors Installed
Fortinet FortiASIC CP9/NP6Lite
Networking
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Performance
Firewall throughput (1518-byte UDP): 20 Gbps
Firewall throughput (512-byte UDP): 20 Gbps
Firewall throughput (64-byte UDP): 9 Gbps
Firewall latency (64-byte UDP): 3 µs
Firewall throughput: 13.5 Mpps
VPN throughput (512-bit IPSec): 9 Gbps
VPN throughput (SSL): 300 Mbps
IPS throughput (HTTP): 6 Gbps
IPS throughput: 2.2 Gbps
SSL inspection throughput: 1 Gbps
Application control (AVC) throughput: 3.5 Gbps
NGFW throughput: 1.8 Gbps
Threat prevention throughput: 1.2 Gbps
CAPWAP throughput: 1.5 Gbps
Capacity
Concurrent TCP sessions: 2000000
New sessions per second: 135000
Firewall policies: 10000
Gateway to gateway IPSec VPN Tunnels: 2000
Client to gateway IPSec VPN tunnels: 5000
Concurrent SSL VPN users: 300
Number of FortiAP devices: 128
Number of FortiClient devices: 600
Virtual domains: 10
Number of FortiToken devices: 1000
Features
Firewall protection, VPN support, content filtering, manageable, High Availability, Intrusion Prevention System (IPS), anti-virus protection
Expansion / Connectivity
Interfaces
14 x 1000Base-T - RJ-45
4 x 1000Base-X - SFP (mini-GBIC)
2 x 1000Base-T - RJ-45 (WAN)
2 x 1000Base-T (management) - RJ-45
1 x USB 2.0 - Type A
1 x console - RJ-45
Miscellaneous
Included Accessories
4 rubber feet, 2 rack mount brackets
Cables Included
1 x network cable
1 x console cable
Compliant Standards
UL, VCCI, BSMI, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC Part 15 B Class A, RCM
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
70.98 Watt
Manufacturer Warranty
Service & Support
Extended service agreement - advance parts replacement - 3 years - response time: next business day
Technical support - phone consulting - 3 years
Technical support - web support - 3 years
Product info support - e-mail consulting - 3 years
Product info support - web knowledge base access - 3 years
New releases update - 3 years
Virus definitions update - 3 years
Intrusion definitions update - 3 years
URL Database update - 3 years
E-mail database update - 3 years
