General
Device Type
Video conferencing kit
Kit Content
Logitech Tap IP, Logitech Rally Bar Mini
Video Input
Type
Digital video camera (colour) - desktop
Interface Type
SuperSpeed USB 3.0
Video Modes
480p, 720p, 1080p, 4K, 1440p, 900p
Camera Mechanical Design
Pan / tilt
Features
RightLight technology, RightSound technology, Acoustic Echo Cancellation (AEC), 30 fps, 120° diagonal field of view, 113° field of view (horizontal), RightSight technology, Voice Activity Detector (VAD), -25° / +25° pan, -15° / +15° tilt, RightSense technology, AI Viewfinder technology, 80.7° field of view (vertical)
Audio Input
Type
6-microphone array - integrated
Microphone Operation Mode
Beamforming
Frequency Response
90 - 16000 Hz
Audio Output
Total Harmonic Distortion (THD)
<2%
Input Device
Type
Remote control, 10.1" touchscreen
Connectivity Technology
Wireless, wired
Networking
Connectivity Technology
Wireless, wired
Data Link Protocol
Ethernet, Fast Ethernet, Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Features
MIMO technology, cable management, AES encryption
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Expansion / Connectivity
Interfaces
1 x audio / video - HDMI input
2 x audio / video - HDMI output
1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45
3 x SuperSpeed USB 3.0
1 x USB-C 3.0
Microphone - input
Miscellaneous
Cables Included
1 x HDMI cable - 2 m
1 x USB 3.0 Type C to Type A cable - 2.2 m
Included Accessories
Lens cap
Software Certification
Zoom Certified
Compliant Standards
Plug and Play, AES-128
Power
Power Device
Power adapter - external
Voltage Required
AC 100-240 V
Manufacturer Warranty
Service & Support
Limited warranty - 2 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 95%
