1310nm FP LD
Multi Data Rate: 125M to 1.25Gbps, NRZ
Single +3.3V Power Supply
AC/AC Differential Electrical Interface
RoHS Compliant and Lead-free
Compliant with Multi-Source Agreement (MSA) Small Form Factor Pluggable (SFP)
Single LC Connector
Compliance with specifications for IEEE802.3z Gigabit Ethernet at 1.25Gbps
Compliance with ANSI specifications for Fiber Channel applications at 1.06bps
Eye Safety Designed to meet LASER Class 1 comply with EN60825-1
Prestatie
SFP transceiver type
Vezel-optiek
Maximale overdrachtssnelheid van gegevens
1250 Mbit/s
Single-mode glasvezelkabel (SMF) ondersteund
Ja
Vezel-optische connector
LC
Vezelkabel diameters ondersteund
9/125 µm
Tx vermogen (min)
-9 dBmW
Tx vermogen (max)
-3 dBmW
Netwerkstandaard
IEEE 802.3z
Certificaten
Certificaten van naleving
RoHS
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 70 °C
Temperatuur bij opslag
-40 - 85 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent
Inhoud van de verpakking
Aantal per verpakking
1 stuk(s)
Logistieke gegevens
Code geharmoniseerd systeem (HS)
85369010
