HPE Aruba Networking CX 6300M 24p 10M/100M/1G 4p SFP56 50G TAA Switch. Switchingcapaciteit: 448 Gbit/s
Data-uitwisseling
Switchingcapaciteit
448 Gbit/s
Prestatie
Physical stacking (units)
10
Frequentie van processor
1800 MHz
Energie
Energieverbruik opmerking
Idle: 49W 100% Traffic Rate: 64W
Netvoeding voetnoot
2 field‑replaceable, hot‑swappable power supply slots 1 minimum power supply required (ordered separately). Supports JL085A PSU.
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Nee
Overige specificaties
Latentie
1 Gbps: 2.28 μs 10 Gbps: 1.46 μs 25 Gbps: 1.90 μs 50 Gbps: 3.49 μs
Geheugen en processor
CPU: Dual-core Arm Cortex-A9 @ 1.8GHz Memory: 8 GB DDR4, 32 GB eMMC Flash: 8 MB, 16 MB, or 32 MB, depending on model and configuration
Prestatiebeheer
Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch Multi-Edit Software
Fan
Switch has two fan tray slots and comes with one fan tray installed. Minimum one fan trays required. Optional second fan tray ordered separately. Fan trays are field replaceable and hot‑swappable. Each fan tray contains two fans.
Aansluitingen
24-port 10/100/1000 BaseT ports 4x 1G/10G/25G/50G [4] SFP ports 1x USB‑C Console Port 1x OOBM port 1x USB Type A Host port
Gewicht (imperiaal)
6,02 kg (13.3 lbs)
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 45 °C
