Poorten & interfaces
Aantal basis-switching RJ-45 Ethernet-poorten
0
Type basis-switching RJ-45 Ethernet-poorten
Nee
Aantal geïnstalleerde SFP modules
0
Aantal geïnstalleerde SFP+ modules
0
Aantal moduleslots SPF+
48
Aantal USB Type-A-poorten
1
Console port
RJ-45/USB Type-C
Netwerk
Netwerkstandaard
IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3ba, IEEE 802.3bj, IEEE 802.3by, IEEE 802.3bz, IEEE 802.3cc, IEEE 802.3cd, IEEE 802.3x, IEEE 802.3z
Spanning tree protocol
Ja
Virtuele LAN-functies
Port-based VLAN
Data-uitwisseling
MAC-adrestabel
147456 entries
Switchingcapaciteit
1760 Gbit/s
Jumbo Frames ondersteuning
Ja
Packet buffergeheugen
32 MB
Beveiliging
DHCP-functies
DHCP relay, DHCP server
Access Control List (ACL)
Ja
Authenticatie type
RADIUS, TACACS+
Multicast-functies
Multicast-ondersteuning
Ja
IPv4-multicast-vermeldingen
4096
IPv6-multicast-vermeldingen
4096
Protocollen
Beheerprotocollen
SNMPv2c, SNMPv3
Routing protocols
BGP, BGP4, OSPF, RIP-2, RIPng, VRRP
IPv4- & IPv6-functies
IPv4/IPv6 access-control list (ACL)
Energie
Vermogenstoevoer inclusief
Nee
AC-ingangsspanning
200 - 240 V
AC-ingangsfrequentie
47/63 Hz
Vermogensverbruik (max)
450 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Nee
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 45 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
15 - 95 procent
Luchtvochtigheid bij opslag
15 - 95 procent
Hoogte, in bedrijf
0 - 3048 m
Hoogte bij opslag
0 - 4600 m
Warmtedissipatie
1535 BTU/h
