Poorten & interfaces
Aantal basis-switching RJ-45 Ethernet-poorten
24
Type basis-switching RJ-45 Ethernet-poorten
10G Ethernet (100/1000/10000)
Aantal geïnstalleerde SFP modules
0
Aantal geïnstalleerde SFP+ modules
0
Aantal moduleslots SPF+
4
Aantal USB Type-A-poorten
1
Console port
RJ-45/USB Type-C
Netwerk
Netwerkstandaard
IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3ba, IEEE 802.3bj, IEEE 802.3by, IEEE 802.3bz, IEEE 802.3cc, IEEE 802.3cd, IEEE 802.3x, IEEE 802.3z
Spanning tree protocol
Ja
Ethernet LAN, data-overdrachtsnelheden
1000,2500,5000,10000 Mbit/s
Virtuele LAN-functies
Port-based VLAN
Data-uitwisseling
MAC-adrestabel
147456 entries
Switchingcapaciteit
1360 Gbit/s
Jumbo Frames ondersteuning
Ja
Packet buffergeheugen
32 MB
Beveiliging
DHCP-functies
DHCP relay, DHCP server
Access Control List (ACL)
Ja
Authenticatie type
RADIUS, TACACS+
Protocollen
Beheerprotocollen
SNMPv2c, SNMPv3
Routing protocols
BGP, BGP4, OSPF, RIP-2, RIPng, VRRP
Design
Overtollige fans ondersteuning
Ja
Luchtstroomrichting
Luchtstroom van voren naar achteren
Aantal ventilatoren
3 ventilator(en)
Energie
Vermogenstoevoer inclusief
Ja
AC-ingangsspanning
200 - 240 V
AC-ingangsfrequentie
47/63 Hz
Vermogensverbruik (max)
400 W
Energieverbruik opmerking
Maximum: 400W Idle: 120W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Nee
Overige specificaties
Geheugen en processor
CPU: Quad Core Arm Cortex™ A72 @ 1.8 GHz Memory and flash: 16 GB RAM, 32 GB Flash/storage Packet buffer: 32 MB
Prestatiebeheer
RJ-45 serial and USB-C console RJ-45 Ethernet port USB Type-A
Fan
3 field-replaceable and hot-swappable fans
Aansluitingen
24 ports of 100M/1/2.5/5/10GbE 4 ports of 1/10GbE (SFP/SFP+) 4 ports of 40/100GbE (QSFP+/QSFP28)
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
15 - 95 procent
Luchtvochtigheid bij opslag
15 - 95 procent
Hoogte, in bedrijf
0 - 3048 m
Hoogte bij opslag
0 - 4600 m
Warmtedissipatie
1364 BTU/h
