Poorten & interfaces
Aantal basis-switching RJ-45 Ethernet-poorten
0
Type basis-switching RJ-45 Ethernet-poorten
Nee
Aantal geïnstalleerde SFP modules
0
Aantal geïnstalleerde SFP+ modules
0
Vezel-optische connector
QSFP28, SFP28
Console port
RJ-45/Micro-USB
Netwerk
Netwerkstandaard
IEEE 802.1AX, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1s, IEEE 802.1t, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3by, IEEE 802.3x, IEEE 802.3z
Spanning tree protocol
Ja
Ethernet LAN, data-overdrachtsnelheden
1000,10000,25000,40000,100000 Mbit/s
Virtuele LAN-functies
Port-based VLAN
Multicast-functies
IPv4-multicast-vermeldingen
4094
IPv6-multicast-vermeldingen
4094
Protocollen
Routing protocols
BGP4, OSPF, RIP, RIPng, RIP-2
Design
Ventilatiesysteem
Luchtstroom van voren naar achteren
Aantal ventilatoren
6 ventilator(en)
Energie
Vermogenstoevoer inclusief
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
Stroomverbruik (typisch)
550 W
Vermogensverbruik (max)
753 W
Energieverbruik opmerking
Maximum: 753W Idle: 400W
Netvoeding voetnoot
Field-replaceable, hot-swappable, and up to two power supplies
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Nee
Overige specificaties
Latentie
<1 µs (without redirect) <5 µs (with redirect)
Geheugen en processor
CPU: Intel Xeon D-1637 6-core processor at 2.90 GHz Switch memory, drive and flash: 32 GB RAM, 64 GB SSD
Prestatiebeheer
CLI REST API SNMP HPE Aruba Networking Fabric Composer HPE Aruba Networking Switch Multi-Edit Software HPE Aruba Networking Central RJ-45 serial port AMD Pensando PSM Micro USB console
Fan
Field-replaceable, hot-swappable and up to six fans
Aansluitingen
48 x 25GbE SFP+, 6 x 100Gb QSFP
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 85 procent
Luchtvochtigheid bij opslag
5 - 95 procent
Warmtedissipatie
1,876 BTU/h
