Poorten & interfaces
Aantal basis-switching RJ-45 Ethernet-poorten
0
Type basis-switching RJ-45 Ethernet-poorten
Nee
Aantal moduleslots SPF+
48
Netwerk
Netwerkstandaard
IEEE 802.1D, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ah
Spanning tree protocol
Ja
Data-uitwisseling
Switchingcapaciteit
336 Gbit/s
Latentie (10 Gbps)
1,2 µs
Jumbo Frames ondersteuning
Ja
Packet buffergeheugen
8 MB
Beveiliging
DHCP-functies
DHCP client, DHCP server
Access Control List (ACL)
Ja
Protocollen
Routing protocols
BGP, IP, MPLS, OSPF, RIP, VRRP
Prestatie
Physical stacking (units)
9
Energie
Vermogenstoevoer inclusief
Ja
AC-ingangsspanning
100 - 240 V
DC voltage input
48 - 60 V
Vermogensverbruik (max)
250 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Nee
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 45 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Warmtedissipatie
327,6 BTU/h
Logistieke gegevens
Code geharmoniseerd systeem (HS)
85176990
