General
Bundled with
2 x NetMod Bays
Processor / Memory / Storage
Networking
Form Factor
Rack-mountable
Connectivity Technology
Wired
Performance
NGFW throughput: 26 Gbps
Maximum throughput FW + AVC2: 27 Gbps
Maximum throughput FW + AVC: 10 Gbps
IPSec VPN throughput (1024B TCP w/Fastpath): 8 Gbps
Maximum inspection throughput: 80 Gbps
Multiprotocol firewall throughput: 40 Gbps
IPsec VPN throughput (450B UDP L2L test): 15 Gbps
Capacity
New connections per second: 848000
Concurrent connections: 15000000
Latency: 3.5
Features
VLAN support, High Availability, URL filtering, DDos attack prevention, clustering technology, 6 fans, Application Visibility and Control (AVC)
Expansion / Connectivity
Expansion Slots
2 (total) / 0 (free) x expansion slot
Interfaces
8 x 10Gb Ethernet - SFP+
1 x 1000Base-T (management) - SFP (mini-GBIC)
1 x serial - RJ-45
1 x USB 2.0 - Type A
Miscellaneous
Included Accessories
Rack rails kit
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, VCCI Class A, KN24, KN22 Class A, AS/NZS CISPR22:2004 Class A, EN 55022 Class A, FCC CFR47 Part 15 B Class A, CNS 13438 Class A, EN 300 386, TVCN 7317, CAN/CSA-C22.2 No. 60950-1
Power
Power Device
Internal power supply - hot-plug
Voltage Required
AC 120/230 V / DC -40 -60 V (50 - 60 Hz)
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
