General
Device Type
Security appliance
Processor / Memory / Storage
Processors Installed
1 x Fortinet FortiASIC SOC4
Networking
Form Factor
Desktop / wall / DIN rail mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol
IPSec, HTTPs
Remote Management Protocol
HTTPS, MQTT
Performance
Firewall throughput (1518-byte UDP): 6 Gbps
Firewall throughput (512-byte UDP): 6 Gbps
Firewall throughput (64-byte UDP): 5.95 Gbps
Firewall latency (64-byte UDP): 3.1 µs
Firewall throughput: 8.9 Mpps
VPN throughput (512-bit IPSec): 3.5 Gbps
VPN throughput (SSL): 400 Mbps
SSL inspection throughput: 460 Mbps
Application control throughput: 1.3 Gbps
IPS throughput: 950 Mbps
NGFW throughput: 550 Mbps
Threat protection throughput: 500 Mbps
Capacity
Concurrent TCP sessions: 600000
New TCP sessions per second: 19000
Firewall policies: 5000
Gateway to gateway IPSec VPN Tunnels: 200
Client to gateway IPSec VPN tunnels: 500
Concurrent SSL VPN users: 100
SSL inspection CPS: 300
SSL inspection concurrent sessions: 70000
Virtual domains: 10
Number of FortiAP devices: 30
Number of FortiAP devices (tunnel): 10
Number of FortiToken devices: 500
Number of FortiSwitches: 16
Features
Fanless, CoAP support, SD-WAN support, CIP support
Encryption Algorithm
SSL, 256-bit AES, 256-bit SHA, TLS 1.3
Expansion / Connectivity
Interfaces
2 x 1000Base-T/1000Base-X - RJ-45/SFP (mini-GBIC) (WAN)
4 x 1000Base-T - RJ-45
1 x USB 3.0 - Type A
1 x console - RJ-45
1 x serial - DB-9
Miscellaneous
Compliant Standards
UL, cUL, CB, FCC Part 15 A, IP20, VCCI Class A, RCM, IEC 61850-3, IEEE 1613
Power
Power Device
External power adapter
Power Consumption Operational
21 Watt
Software / System Requirements
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
75 °C
Humidity Range Operating
20 - 90% (non-condensing)
