General
Device Type
Security appliance
Bundled Services
5 years 24x7 FortiCare Support + 5 years FortiGuard Unified Threat Protection (UTP)
Processor / Memory / Storage
Processors Installed
1 x Fortinet FortiASIC SOC4
Networking
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol
IPSec
Performance
IPS throughput: 1.4 Gbps
NGFW throughput: 1 Gbps
Threat protection throughput: 900 Mbps
Firewall throughput (1518-byte UDP): 10 Gbps
Firewall throughput (512-byte UDP): 10 Gbps
Firewall throughput (64-byte UDP): 7 Gbps
Firewall latency (64-byte UDP): 4 µs
Firewall throughput: 10.5 Mpps
VPN throughput (512-bit IPSec): 6.5 Gbps
VPN throughput (SSL): 950 Mbps
VPN throughput (SSL): 950 Mbps
SSL inspection throughput: 715 Mbps
Application control throughput: 1.8 Gbps
CAPWAP throughput: 9 Gbps
Capacity
Concurrent TCP sessions: 1500000
New TCP sessions per second: 45000
Firewall policies: 5000
Gateway to gateway IPSec VPN Tunnels: 200
Client to gateway IPSec VPN tunnels: 2500
Concurrent SSL VPN users: 200
SSL inspection CPS: 700
SSL inspection concurrent sessions: 100000
Virtual domains: 10
Number of FortiAP devices: 32
Number of FortiAP devices (tunnel mode): 16
Number of FortiToken devices: 500
Features
VPN support, fanless, 3G/4G USB Dongle Support
Encryption Algorithm
SSL, TLS 1.3
Expansion / Connectivity
Interfaces
8 x 1000Base-T - RJ-45
2 x 1000Base-T/1000Base-X - RJ-45/SFP (mini-GBIC) (WAN)
1 x USB 3.0 - Type A
1 x console - RJ-45
Miscellaneous
Compliant Standards
UL, VCCI, BSMI, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC, ICES, RCM, ICSA SSL-VPN, ICSA IPS
Power
Power Device
External power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
16.5 Watt
Software / System Requirements
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
