General
Device Type
Security appliance
Processor / Memory / Storage
Processors Installed
1.6 GHz
Hard Drive
SSD 480 GB x 1 - M.2 NVMe
Networking
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Performance
Stateful inspection firewall throughput: 6.5 Gbps
Stateful inspection firewall throughput (multiprotocol): 6 Gbps
IPsec VPN throughput (450B UDP L2L test): 5.5 Gbps
Capacity
Maximum concurrent sessions with AVC: 175000
Concurrent firewall connections: 200000
Maximum VPN peers: 200
Status Indicators
Link/activity/speed, management, PoE, alarm, system, power
Features
High Availability, 120W PoE power budget, reset button, 1 fan, auto duplex mode, auto-uplink (auto MDI/MDI-X)
Compliant Standards
IEEE 802.3at
Expansion / Connectivity
Interfaces
4 x 1000Base-T - RJ-45
4 x 1000Base-T (PoE) - RJ-45 - 30 W
1 x serial / console - RJ-45
1 x management - RJ-45
1 x USB 3.0 - Type A
1 x USB - Type C
Miscellaneous
Cables Included
1 x console cable - 1.82 m
Compliant Standards
UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, UL 62368-1, CAN/CSA-C22.2 No. 62368-1, EN 62368-1, IEC 62368-1, AS/NZS 62368-1, FCC CFR 47 Part 15 Class A, AS/NZS CISPR22 Class A, CISPR 22 Class A, EN 55022 Class A, ICES-003 Class A, VCCI Class A, EN 61000-3-2, EN61000-3-3, KN22 Class A, CNS 13438 Class A, EN 300386, TCVN 7189, EN55024, CISPR 24, KN24, TVCN 7317, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
Power
Power Over Ethernet (PoE) Supported
PoE
Power Device
External power adapter
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Operational
32 Watt
Software / System Requirements
Software Included
Cisco ASA 9.22.1, Cisco Essentials
Manufacturer Warranty
Service & Support
Limited warranty - replacement - 90 days - response time: 10 days
Environmental Parameters
Min Operating Temperature
0 ?C
Max Operating Temperature
40 ?C
Humidity Range Operating
5 - 85% (non-condensing)
