General
Device Type
Security appliance
Processor / Memory / Storage
Networking
Connectivity Technology
Wired
Data Link Protocol
Gigabit Ethernet, 10 Gigabit Ethernet
Network / Transport Protocol
TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP
Routing Protocol
OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR)
Remote Management Protocol
SNMP 2, SNMP 3, HTTP, HTTPS, SSH, CLI
Performance
Firewall throughput: 5 Gbps ¦ Threat prevention throughput: 2.5 Gbps ¦ Application throughput: 3 Gbps ¦ IPS throughput: 3 Gbps ¦ Anti-malware throughput: 2.5 Gbps ¦ TLS/SSL inspection and decryption throughput: 800 Mbps ¦ VPN throughput (IPSec): 2.1 Gbps ¦ Connection rate: 25000 connections per second
Capacity
Virtual interfaces (VLANs): 256 ¦ SSL VPN licences: 2 (maximum 250) ¦ VPN tunnels (site-to-site): 250 ¦ IPSec VPN clients: 10 (maximum 500) ¦ SPI connections: 1500000 ¦ DPI connections: 500000 ¦ DPI SSL connections: 75000 ¦ Single Sign-On (SSO) users: 2500 ¦ Manageable access points: 32
Features
Firewall protection, NAT support, VPN support, PAT support, VLAN support, Stateful Packet Inspection (SPI), DoS attack prevention, content filtering, port mirroring, IPv6 support, antivirus analysis, deep inspection, DDos attack prevention, anti-spam protection, Quality of Service (QoS), Dead Peer Detection (DPD), IPSec NAT-Traversal (NAT-T), Jumbo Frames support, DHCP server, bandwidth control, IPv4 support, Common Access Card (CAC) reader support, DHCP relay, 3G/4G USB Dongle Support, NetFlow, Single Sign-On (SSO) support, VLAN trunking, SD-WAN support
Encryption Algorithm
DES, Triple DES, MD5, SHA-1, 128-bit AES, 192-bit AES, 256-bit AES
Authentication Method
RADIUS, LDAP, XAUTH authentication
IP Telephony
VoIP Protocols
SIP, H.323 v3, H.323 v4, H.323 v1, H.323 v2, H.323 v5
Expansion / Connectivity
Interfaces
6 x 1000Base-T - RJ-45 ¦ 2 x 1000Base-T - RJ-45 (WAN) ¦ 2 x network - SFP+ ¦ 2 x USB 3.0 - Type A ¦ 1 x console - RJ-45 ¦ 1 x console - micro-USB
Miscellaneous
Compliant Standards
FCC Class B certified, UL, TUV GS, C-Tick, BSMI, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FIPS 140-2 Level 2, EMC, RoHS, ICES Class B, KCC, WEEE, ANATEL, REACH, LVD, VCCI Class B, MSIP, Common Criteria
Power
Power Device
External power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
13.1 Watt
Software / System Requirements
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
