General
Device Type
Wireless router - 4-port switch (integrated)
Connectivity Technology
Wired, wireless
Data Link Protocol
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Ethernet, Fast Ethernet, Gigabit Ethernet
Frequency Band
2.4 GHz / 5 GHz
Performance
Maximum data rate (2.4 GHz): 300 Mbps
Maximum data rate (5 GHz): 867 Mbps
Network / Transport Protocol
PPPoA, PPPoE, IPoE, IPv4, IPv6, DHCP
Routing Protocol
IGMP, IGMPv2, IGMPv3
Remote Management Protocol
HTTP, TR-181 i2, TR-098, TFTP, TR-111, SNMP 1, SNMP 2
Encryption Algorithm
WPA2, WPA2-PSK, TKIP, AES
Features
MAC encapsulation routing, NAT support, DHCP client, DHCP relay, DHCP server, DNS proxy, dynamic DNS, policy route, WPS, WMM support, MU-MIMO technology, DoS attack prevention, parental control, packet filtering, 3G USB Dongle Support, file sharing, Rom-D support, remote firmware upgrade, G.Vector, G.INP
Compliant Standards
IEEE 802.1D, IEEE 802.1Q, UPnP, LVD, EMC
Status Indicators
Power, WAN, Internet, 2.4 GHz, 5 GHz, WPS, LAN
Communications
Digital Signaling Protocol
VDSL2, ADSL2, ADSL2+
Protocols & Specifications
ITU G.993.1, ITU G.993.2, ITU G.992.1 (G.DMT), ITU G.992.2 (G.Lite), ITU G.992.3, ITU G.992.5
IP Telephony
Voice Codecs
G.711a, G.711u, G.722, G.726
IP Telephony Features
RFC 3261 support, echo cancellation (G.168), voice activity detection (VAD), comfort noise generation (CNG), dynamic jitter buffer, DTMF generation/detection, DTMF inband, DTMF out-of-band, on hook, off hook and flash detection, Caller ID, call forwarding, call transfer, Call Hold/Retrieve, call conference, call waiting
Expansion / Connectivity
Interfaces
LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45
WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
WAN: 1 x VDSL2 / ADSL2+ - RJ-11
USB 2.0: 1 x
Aerial
Power
Power Device
External power adapter
Miscellaneous
Included Accessories
Power adapter
Cables Included
1 x network cable
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
