General
Device Type
Switch - 16 ports - Managed - stackable
Enclosure Type
Rack-mountable 1U
Ports
4 x 2.5GBase-T + 8 x 100/1000/10GBase-T + 2 x 100/1000/10GBase-T + 2 x 10 Gigabit SFP+
Power Over Ethernet (PoE)
PoE
Performance
Throughput: 172 Mbps ¦ Switching capacity: 116 Gbps ¦ Latency (100 Mbps): 4.1 µs ¦ Latency (1 Gbps): 1.8 µs ¦ Latency (10 Gbps): 2.8 µs ¦ Latency (2.5 Gbps): 6.7 µs
Capacity
MAC address entries: 16000 ¦ Routing table entries (static): 992 ¦ IPv6 routes (static): 512 ¦ IPv4 routes (static): 512
MAC Address Table Size
16000 entries
Jumbo Frame Support
9216 bytes
Routing Protocol
Static IP routing
Remote Management Protocol
SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, RADIUS
Authentication Method
RADIUS
Features
Flow control, DHCP support, auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, IPv6 support, half duplex mode, full duplex mode, Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Trusted Platform Module (TPM), Link Aggregation Control Protocol (LACP), Class of Service (CoS), Energy-Efficient Ethernet (EEE), BPDU Filter, auto voice VLAN, Media Endpoint Discovery (LLDP-MED)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1s, IEEE 802.1ab (LLDP)
Processor
1 x ARM CortexTM A9: 800 MHz
Expansion / Connectivity
Interfaces
8 x 10/100/1000 Base-T (PoE) RJ-45 480 W ¦ 4 x 1/2.5G (PoE+) RJ-45 480 W ¦ 2 x 10 Gigabit Ethernet / 10 Gigabit Ethernet SFP+ SFP+ ¦ 2 x 10/100/1000 Base-T
Power
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Miscellaneous
Compliant Standards
EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3, ICES-003 Class A, VCCI Class A, CNS 13438 Class A, KN35, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, AS/NZS CISPR 32 Class A, KN32 Class A, IEC/EN 61000-4-11, IEC/EN 61000-4-2, UL 62368-1 Second Edition, IEC/EN60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013, EN 55032:2015 Class A, CISPR 32:2015 Class A, UL 62368-1, EN 55035, CISPR 35, IEC/EN 60825-1:2014 Class 2, IEC/EN 62368-1, UL 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1 Second Edition, FCC CFR47 Part 15 B Class A 2018
Localisation
English / Europe
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty ¦ Technical support - phone consulting - 90 days
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
15 - 95% (40 °C)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
15 - 90% (non-condensing)
